Ball valves - automatically operated

Ball valve with electrical actuator; Female thread; Body, Ball 1.4571; Seals PEEK/FKM; For liquids; Medium temperature -20...+100°C; G 1/4"; Nominal diameter 10mm; Pressure range 0-400bar; Operating time 8s; Voltage 24VAC/DC

BA066-38-0L

Ball valve with electric actuator, female thread, body 1.4571, seals PEEK/FKM, medium temperature -20...+100°C, G 3/8", DN 10mm, pressure range 0-400bar, face-to-face length 73mm, actuating time 8sec., voltage 24VAC/DC

BA068-114-0L

Ball valve with electrical actuator; Female thread; Body, Ball 1.4571; Seals POM/NBR; Medium temperature -20...+100°C; For neutral gases; G 11/4"; Nominal diameter 32mm; Pressure range 0-350bar; Length 110mm; Actuator VB190; Operating time 27s; Voltage 24VAC/DC

BA068-114-D0

Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4571; Seals POM/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; G 11/4"; Nominal diameter 32mm; Pressure range 0-350bar; Actuator PAD100

BA069-12-CL-01

BA069-12-L-01
Ball valve made of stainless steel; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE-Reinforced with carbographite/FKM; Medium temperature -20...+160°C; Connection RP 1/2"; Nominal diameter 15mm; Pressure range 0-140bar; Length 66mm; V-Ball 30-60°
VB030-L-P0S
Electrical actuator Series VB; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Incl. Positioner 4-20mA/0-10V; Torque 30Nm; Operating time 8s; Flange ISO5211 F03/F05-Stern 11 mm; Voltage 24VAC/DC; Protection class IP67
VK1109
Square adapter Series VK; 11X9; Length 10mm; Material Stahl

BA069-20-0R

Ball valve with electrical actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -10...+160°C; RP 2"; DN 50mm; Pressure range 0-64bar; Length 131mm; Operating time 30s; Voltage 24-240VAC/DC

BA069-20-S0-P1-01

Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0...64bar; Length 131mm; Actuator PAS1155; Mounted pilot valve; NAMUR; Standard coil MA22; Connector size 22mm; 3/2-way solenoid valve - NAMUR type (MNH-310-701-01); 24VDC; Incl. Technical valve passport RU According to TR CU 032/2013; Incl. TR CU 032/2013 (Incl. Strength calculation), TR CU 010/2011; Incl. EAC-Certificate

BA073-40-0B-01

Flanged ball valve with electrical actuator; Length According to EN558−1 R1; Body 1.4408; Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 40mm; Pressure range 0-40bar; Flange PN40; Length 200mm; Operating time 6s; Voltage 230VAC; Protection class IP67; Position feedback Above TAM; 4…20mA

BA073-40-0M-01

Flanged ball valve with electrical actuator; Flange PN40; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R1; Full bore; Body, Ball 1.4408; Seals PTFE/Graphoil/FKM; Medium temperature -20...+160°C; DN 40mm; Pressure range 0...40bar; Length 200mm; Actuator AUMA SQ05.2; Incl. AUMA-MATIC AM01.1 Operating time 22s; Voltage 400V/50Hz

BA077-50-S0-01

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE-Fibre-glass-reinforced/EPDM; Compensation hole; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -35...+140°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator Low temperature design PAS1005-L

BA080-10-0F-C

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 1"; DN 25mm; Pressure range 0-40bar; Length 90mm; Operating time 7s; Voltage 100-240VAC; Electrical actuator CSA-Certified

BA080-10-0L-03

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM/EPDM; Medium temperature 0...+160°C; RP 1"; DN 25mm; Pressure range 0-40bar; Length 90mm; Operating time 10s; Voltage 24VAC/DC; Stem extension

BA080-10N-B

Ball valve made of brass; Bare shaft; Female thread; Seal PTFE/FKM; Medium temperature -20...+160°C; Connection NPT1"; Nominal diameter 25mm; Pressure range 0-40bar; Length 85mm; Flange ISO5211 F03; Square 9mm

BA080-10-QH

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 1"; DN 25mm; Pressure range 0-40bar; Length 90mm; Operating time 10s; Voltage 100-240VAC; NO-Accumulator for safety position

BA080-112-S0-A-01

Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM; Single acting actuator; NC; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 11/2"; Nominal diameter 40mm; Pressure range 0-40bar; Length 114mm; Actuator PAS0635; ATEX-Antistatic; Mounted pilot valve; NAMUR; 24VDC; ATEX-ExmbIIT5; Cable length 3m

BA080-114-0F-C

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 11/4"; DN 32mm; Pressure range 0-40bar; Length 102mm; Operating time 7s; Voltage 100-240VAC; Electrical actuator CSA-Certified

BA080-114-D0B-A-01

Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM; Double acting actuator; NC; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 11/4"; Nominal diameter 32mm; Pressure range 0-40bar; Length 102mm; Actuator PAD052; ATEX-Antistatic; Mounted pilot valve; NAMUR; 24VDC; ATEX-ExmbIIT5; Cable length 3m

BA080-114-QH

ball valve with electrical actuator; female thread; housing, ball brass; seals PTFE/FKM; medium temperature 0...+100°C; RP 11/4"; DN 40mm; pressure range 0-40bar; length 104mm; operating time 8s; voltage 100-240V50-60Hz; NO-accumulator for safety position

BA080-12-0F-C

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 1/2"; DN 15mm; Pressure range 0-40bar; Length 67mm; Operating time 7s; Voltage 100-240VAC; Electrical actuator CSA-Certified

BA080-12-PH-01

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature -20...+160°C; RP 1/2"; DN 15mm; Pressure range 0-40bar; Length 67mm; Operating time 10s; Voltage 100-240VAC; NC-Accumulator for safety position; With Mounting bridge
