A1N2I6-G-250-PI-ABS42-EPC02400-1-MSU04/2

A1N2I6-G-250-PI
knife gate valve with double acting actuator series A1N-PI; wafer type; body AISI 316; gate AISI 316; soft sealed silicone; packing PTFE-synthetic/silicone; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+200°C; prepared for 2 inductive switches MSU03, MSU04, MSU05; DN 250mm; length 70mm; pressure range 0…8bar
ABS42
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; standard coil C001; connector size 22mm; 5/2-Wege-Magnetventil (E52W1SM14); DN gate valve 50-400mm
EPC02400-1
mounted coil type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; cable length 3m; voltage 24VDC
MSU04/2
electrical position indication series MSU; suitable for knife gate valve; mounted inductive proximity switch, ATEX, EExi (2 pieces); cable length 2m
