Manometer

Hoses, Tubes, Manometer and accessories

Diameter	Connection	Indicating range	Unit	Class	Type	Sequence
80 mm	1/4"	0...1	bar	2,5	231	14750001
80 mm	1/4"	0...1,6	bar	2,5	232	14750002
80 mm	1/4"	0...2,5	bar	1,6	233	14750003
80 mm	1/4"	0...4	bar	1,6	234	14750004
80 mm	1/4"	0...6	bar	1,6	235	14750005
80 mm	1/4"	0...10	bar	1,6	236	14750006
80 mm	1/4"	0...16	bar	1,6	237	14750007
80 mm	1/4"	0...25	bar	2,5	238	14750008
80 mm	1/4"	0...40	bar	2,5	239	14750009

Bourdon tube manometer

Ø 100mm; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear

To Series: Bourdon tube manometer

Grundversion

Diameter	Connection	Indicating range	Unit	Class	Type	Sequence
100 mm	1/4"	-1...0	bar	1,6	250	14760000
100 mm	1/4"	0...1	bar	1,6	251	14760001
100 mm	1/4"	0...1,6	bar	1,6	252	14760002
100 mm	1/4"	0...2,5	bar	1,6	253	14760003
100 mm	1/4"	0...4	bar	2,5	254	14760004
100 mm	1/4"	0...6	bar	2,5	255	14760005
100 mm	1/4"	0...10	bar	1,6	256	14760006
100 mm	1/4"	0...16	bar	1,6	257	14760007
100 mm	1/4"	0...25	bar	2,5	258	14760008

Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 40mm; Indicating range -1/0; Unit bar; Connection 1/8"

To Series: Bourdon tube manometer Series MA001-R

Diameter	Connection	Indicating range	Unit	Type
40 mm	1/8"	-1...0	bar	MA001-40R-V

300/40

Bourdon tube manometer; Body Sheet steel; Front ring Chromium-plated; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 40mm; Indicating range -1/0; Unit bar; Connection 1/8"

To Series: Bourdon tube manometer
