Cylinders

CRW50-60-11

Magnetic rotating cylinder; Pressure range 1...10bar; Adjustable cushions; Sleeve shaft; Diameter 50mm; Rotation angle 60°; Connection 1/4"; Torque at 6bar 26,4Nm

F3-11-350

Hydraulic cushioning cylinder; Stroke 350mm; Speed control Both sides

FAB010/0130/-910

Bellow; Length Max. 130mm; Min. 35mm; Inside diameter 10mm; Outside diameter 24mm; Connection 1: 7x10mm; Connection 2: 16x14mm; Material CR-Rubber

Compact-magnetic guide cylinder Series HCG; Double acting; Diameter 16...50mm; Pressure Max. 10bar; With guide-bearing made of brass or ball bearing; Information Zur Anfrage/Bestellung ist der Typenschlüssel laut Angaben im technischen Datenblatt anzugeben

HNG20-10-BS

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 20mm; Stroke 10mm; Connection 1/8"; Push force at 6 bar 188N; Guide-bearing Brass

HNG25-75-BS-M6

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 25mm; Stroke 75mm; Connection 1/8"; With guide-bearing made of brass; Side mounting holes M6 According to drawing

HNG50-BB-SG

Seal kit PU; Cylinder Series HNG-BB; Diameter 50mm

HNG63-300-BS

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 63mm; Stroke 300mm; Connection 1/4"; Push force at 6 bar 1869N; Guide-bearing Brass

HPSK-BS-16-25

Dual piston magnetic cylinder; Double acting; Pressure range 2...8bar; Diameter 16mm; Stroke 25mm; Guide Slide bearing; Connection M5; Push force at 6 bar 240N; Dimensions Of Stroke 30mm

HPSK-BS-16-75-01

Dual piston magnetic cylinder; Double acting; Pressure range 2...8bar; Diameter 16mm; Stroke limitation to 60mm; With guide-bearing made of brass

HSA-PC26-25

Damper-Holder Suitable to PC26-25; Female thread For Damper M14x1,5

HU-ACM25/45-S01

Mini munkahenger mágnessel, kétoldali működésű; nyomástartomány 1...10bar; szabvány DIN/ISO 6432; állítható löketvégi csillapítással
Ø 25 mm
löket 50 mm
dugattyúrúd menet M10x1
csatlakozás 1/8"
nyomóerő 6 bar-on 295 N

HU-NWT125-75

Profile magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 125mm; Stroke 75mm; Piston rod thread M27x2; Connection 1/2"; Push force at 6 bar 7359N

HU-NWT32-550-S01PIST. R0D

In-house production NWT32-550-S01 piston rod

HU-NWT40-100-S01

Profile magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 40mm; Stroke 100mm; Piston rod thread M14x1,5; Connection 1/4"; Push force at 6 bar 754N
