Pneumatics
| Diameter | Female thread | Type |
|---|---|---|
| 15/12,5 mm | M20x1 | SC33-15-M20X1-N |
Grundversion
| Diameter | Type | Sequence |
|---|---|---|
| 5/3 mm | SC40-05-DA | 5460000 |
| 6/4 mm | SC40-06-D | 5460001 |
| 8/6 mm | SC40-08-D | 5460002 |
Coupling DN 2,5 Series C0C25-M
Male thread; Nickel plated brass; Seal NBR; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Male thread | DN | Type | Sequence |
|---|---|---|---|
| G 1/8" | 2,5 mm | C0C25-M18-N | 5470002 |
| M5 | 2,5 mm | C0C25-MM5-N | 5470003 |
Coupling DN 2,5 Series C0C25-F
Female thread; Nickel plated brass; Seal NBR; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Female thread | DN | Type | Sequence |
|---|---|---|---|
| G 1/8" | 2,5 mm | C0C25-F18-N | 5480002 |
| M5 | 2,5 mm | C0C25-FM5-N | 5480003 |
Coupling DN 2,5 Series C0C25-S
Hose connection; Nickel plated brass; Seal NBR; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Diameter | DN | Type | Sequence |
|---|---|---|---|
| 4/2,5 mm | 2,5 mm | C0C25-S04-N | 5490001 |
| 6/4 mm | 2,5 mm | C0C25-S06-N | 5490005 |
Coupling DN 2,5 Series C0C25-H
Hose nozzle; Nickel plated brass; Seal NBR; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Diameter | DN | Type | Sequence |
|---|---|---|---|
| 3 mm | 2,5 mm | C0C25-H03-N | 5500002 |
| 4 mm | 2,5 mm | C0C25-H04-N | 5500003 |
Coupling plug DN 2,5 Series C0P25-M
Male thread; Nickel plated brass; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Male thread | DN | Type | Sequence |
|---|---|---|---|
| G 1/8" | 2,5 mm | C0P25-M18-N | 5510002 |
| M5 | 2,5 mm | C0P25-MM5-N | 5510003 |
Coupling plug DN 2,5 Series C0P25-F
Female thread; Nickel plated brass; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Female thread | DN | Type | Sequence |
|---|---|---|---|
| G 1/8" | 2,5 mm | C0P25-F18-N | 5520002 |
| M5 | 2,5 mm | C0P25-FM5-N | 5520003 |
Coupling plug DN 2,5 Series C0P25-S
Hose connection; Nickel plated brass; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Diameter | DN | Type | Sequence |
|---|---|---|---|
| 4/2,5 mm | 2,5 mm | C0P25-S04-N | 5530001 |
| 6/4 mm | 2,5 mm | C0P25-S06-N | 5530004 |
Coupling plug DN 2,5 Series C0P25-H
Hose nozzle; Nickel plated brass; Pressure 0...35bar; Temperature -20...80°C
Grundversion
| Diameter | DN | Type | Sequence |
|---|---|---|---|
| 3 mm | 2,5 mm | C0P25-H03-N | 5540002 |
| 4 mm | 2,5 mm | C0P25-H04-N | 5540003 |
