Pneumatics
Male stud branch tee swivel Series PI22-360
Nickel plated brass; Cylindrical thread
Grundversion
| Diameter | Male thread | Type | Sequence |
|---|---|---|---|
| 4 mm | M5 | PI22-04-M5-N-0-360 | 4700000 |
| 4 mm | G 1/8" | PI22-04-18-N-0-360 | 4700001 |
| 6 mm | M5 | PI22-06-M5-N-0-360 | 4700002 |
| 6 mm | G 1/8" | PI22-06-18-N-0-360 | 4700003 |
| 6 mm | G 1/4" | PI22-06-14-N-0-360 | 4700004 |
| 8 mm | G 1/8" | PI22-08-18-N-0-360 | 4700005 |
| 8 mm | G 1/4" | PI22-08-14-N-0-360 | 4700006 |
| 10 mm | G 1/4" | PI22-10-14-N-0-360 | 4700007 |
| 10 mm | G 3/8" | PI22-10-38-N-0-360 | 4700008 |
| 12 mm | G 3/8" | PI22-12-38-N-0-360 | 4700009 |
| 12 mm | G 1/2" | PI22-12-12-N-0-360 | 4700010 |
| Diameter | Type |
|---|---|
| 4 mm | PI10-04-N |
