Valves, butterfly valves and gate valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BUL2A-100-CSRS-L
Butterfly valve with hand lever; ATEX II 2 GD Ex h X; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 100mm; Length 52mm; Nominal flange pressure PN10/16
BULV-100-CSRS-L
Butterfly valve with hand lever; ATEX II 2 GD Ex h X; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 100mm; Length 52mm; Nominal flange pressure PN25
BULG-150-SSFS-B
Butterfly valve with bare shaft; Series BULG-SSFS-B; Lug type; Length According to EN558−1 R20; Body 1.4408; Disc 1.4408; Shaft 1.4408; Liner Silicone Food safe; Medium temperature -10...+190°C; DN 150mm; Length 56mm; Pressure range 0-16bar; Nominal flange pressure 10/16bar
BULG-150-SSFS-B-3C
Butterfly valve with bare shaft; Series BULG-SSFS-B-3C; Lug type; Length According to EN558−1 R20; Body 1.4408; Disc 1.4408; Shaft 1.4408; Liner Silicone Food safe; Medium temperature -10...+190°C; DN 150mm; Length 56mm; Pressure range 0-16bar; Nominal flange pressure 10/16bar; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
SE27-N20-STW-01
Angle seat-Control valve; Manual operated; Body 1.4408; Cone, Stem, Head end Stainless steel 1.4571; Handwheel Steel Plastic coated; Seat seal PTFE; Packing PTFE filled with coal; Back seal; PTFE; Rising stem; Medium temperature -30…+200°C; Pressure range 0...40bar; Thread 2"NPT; DN 50mm; Length 150mm; With control cone; Characteristic linear
BULA-200-DLES-G
butterfly valve with manual gear box; lug type; length according to EN558−1R20; housing ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316 HALAR-coated; shaft AISI 316; liner EPDM; nominal flange pressure PN16; medium temperature -10...+130°C; pressure range 0...16bar; DN 200mm; length 60mm
BUW6-200-CSN-G-3E
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Carbon steel A216-WCB Epoxy coated, Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; Nominal flange pressure PN10/16/ANSI150; Pressure range 0...16bar; DN 200mm; Length 60mm; Notch impact test -29°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULA-100-CSRS-L-A3C
Butterfly valve with hand lever; Lug type; Length According to EN558−1 R20; Body Steel; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16 Medium temperature -10...+230°C; Pressure range 0...16bar; ATEX II 2G/D c TX; DN 100mm; Length 52mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Certificate TR CU; With valve pass And Verify Safety; Notch impact test
BULC-300-DSE-B-A
Butterfly valve with bare shaft; ATEX - II 2GD Ex h X EPT 14; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 300mm; Length 78mm; Pressure range 0…10bar; Nominal flange pressure PN10
BULD-100-DZTS-L
Butterfly valve with hand lever; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4542 PTFE-coated; Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN10/16; Medium temperature -10...+190°C; Pressure range 0...10bar; DN 100mm; Length 52mm
BUW6-250-CSN-L
Butterfly valve with hand lever; Wafer type; Length According to EN558−1 R20; Body Carbon steel A216-WCB Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+100°C; Pressure range 0...16bar; DN 250mm; Length 68mm
BUW6-250-CSN-L-3C
Butterfly valve with hand lever; Wafer type; Length According to EN558−1 R20; Body Carbon steel A216-WCB Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+100°C; Pressure range 0...16bar; DN 250mm; Length 68mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BUW6-300-DSE-G-A
Butterfly valve, ATEX wafer version, face-to-face length to EN558−1 R20, body GGG40 epoxy-coated, disc 1.4408, shaft 1.4016, sleeve EPDM, flange nominal pressure PN10/16/ANSI150, medium temperature -30...+130°C, pressure range 0...16bar, DN 300mm, installation length 78mm
BULY-150-CSV-G-3C01
Butterfly valve with manual gear box; With shut-off flange; Lug type; Length According to EN558−1R20; Body Steel 1.0619; Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner FKM; Medium temperature -10...+200°C; DN 150mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULA-100-CSRS-B
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Carbon steel A216-WCB; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16 Medium temperature -29...+230°C; Pressure range 0...16bar; DN 100mm; Length 52mm
BULA-100-CSRS-B-3C
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Carbon steel A216-WCB; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16 Medium temperature -29...+230°C; Pressure range 0...16bar; DN 100mm; Length 52mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
GL133-80-W
Globe valve; DN80; PN40; Body Steel; Seat Stainless steel 1.4370; Cone, Stem Stainless steel 1.4021; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Rising stem; Medium temperature -10…+400°C; Pressure range 0…40bar; Butt weld ends
BULA-100-CSRS-B-A3C
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Steel; Disc 1.4408; Shaft 1.4542; Seat RTFE; Nominal flange pressure PN16 Medium temperature -10...+230°C; Pressure range 0...16bar; ATEX II 2G/D c TX; DN 100mm; Length 52mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Certificate TR CU; With valve pass And Verify Safety; Notch impact test
BULD-100-DZTS-B
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4542 PTFE-coated; Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN10/16; Medium temperature -10...+190°C; Pressure range 0...10bar; DN 100mm; Length 52mm
GL164-25-W-3C
Needle valve; Body Stainless steel 1.4571; Stem seal PTFE; Medium temperature -20...+250°C; Flange PN16; DN 12mm; Pressure range 0...16bar; Length 130mm; Material handwheel Steel; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness;
