Valves, butterfly valves and gate valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BULV-500-CSRS-G-A
Butterfly valve with manual gear box; ATEX II 2 GD Ex h X; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -10...+230°C; Pressure range 0...25bar; DN 500mm; Length 127mm; Nominal flange pressure PN16
BULY-040-DSE-L-3C
Butterfly valve with hand lever Series BULY-DSE-L-3C; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 40mm; Length 33mm; Pressure range 0-16bar; Nominal flange pressure ANSI150; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-080-SSES-B-01
Butterfly valve with bare shaft Series BUL-SSES-B-01; Lug type; Length According to EN558−1R20; Body; Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 80mm; Length 46mm; Pressure range 0...16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-100-CSN-B-3C-01
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Carbon steel A216-WCB Special-Epoxy coated C5 According to EN-ISO 12944, RAL 7030; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-100-CSN-B-3E-01
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Carbon steel A216-WCB Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Incl. Notch impact test; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-100-DSN-B-3C02
butterfly valve with bare shaft; lug type; length according to EN558−1R20; housing ductile iron EN-GJS-400-15 C5M RAL7044-coated according to EN-ISO 12944; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 100mm; length 52mm; pressure range 0…16bar; nominal flange pressure ANSI150; flange thread 5/8"UNC; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
BULY-100-DSN-B-3C03
butterfly valve with bare shaft; lug type; length according to EN558−1R20; housing ductile iron EN-GJS-400-15 painted RAL7044; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 100mm; length 52mm; pressure range 0…16bar; nominal flange pressure ANSI150; flange thread 5/8"UNC; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
BULY-100-SSES-B-01
Butterfly valve with bare shaft Series BUL-SSES-B-01; Lug type; Length According to EN558−1 R20; Body; Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-125-DSE-B-01
Butterfly valve with bare shaft Series BULY-B-01; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-125-DSE-B-02
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-125-DSE-B-02-3C
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-125-DSE-L-02
Butterfly valve with hand lever; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0...16bar; Flange ANSI150; Flange thread UNC
BULY-125-DSE-L-02-3C
Butterfly valve with hand lever; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0...16bar; Flange ANSI150; Flange thread UNC
BULY-125-DSE-L-3C-01
Butterfly valve with hand lever; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0-16bar; Flange ANSI150; Flange thread UNC
BULY-125-SSES-B-01
Butterfly valve with bare shaft Series BUL-SSES-01; Lug type; Length According to EN558−1R20; Body; Disc And Shaft 1.4408; Liner EPDM; Medium temperature -10...+130°C; DN 125mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-150-CSV-B-A01
butterfly valve with bare shaft; ATEX - II 2GD Ex h X EPT 14; lug type; length according to EN558−1R20; housing steel C5M-coated according to EN-ISO 12944; disc AISI 316; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 150mm; length 56mm; pressure range 0…16bar; nominal flange pressure ANSI150
BULY-150-CSV-L-A01
butterfly valve with hand lever; ATEX - II 2GD Ex h X EPT 14; lug type; length according to EN558−1R20; housing steel C5M-coated according to EN-ISO 12944; disc AISI 316; shaft AISI 430; liner FKM; medium temperature -10...+200°C; DN 150mm; length 56mm; pressure range 0…16bar; nominal flange pressure ANSI150
BULY-150-DSE-B-02
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC
BULY-150-DSE-B-02-3C
Butterfly valve with bare shaft; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-150-DSE-L-02
Butterfly valve with hand lever; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5002; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0-16bar; Flange ANSI150; Flange thread UNC
