Valves, butterfly valves and gate valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BULY-200-SSRS-B-3D
Butterfly valve with bare shaft; Lug type; Length According to EN558−1 R20; Body And Disc 1.4408; Shaft 1.4542; Seat RTFE; Medium temperature -10...+230°C; DN 200mm; Length 61mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; Certificate TR CU; With valve pass And Verify Safety
BUW4-200-DZTS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Stainless steel 1.4542 PTFE-coated; Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+190°C; Pressure range 0...10bar; DN 200mm; Length 60mm
BUW4-200-DZTS-G-3C
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Stainless steel 1.4542 PTFE-coated; Shaft 1.4408; Liner PTFE/silicone; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+190°C; Pressure range 0...10bar; DN 200mm; Length 60mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULY-250-CSV-L-3C01
Butterfly valve with hand lever Series BULY-CSV-L-3C01; Lug type; Length According to EN558−1 R20; Body Steel 1.0619; Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner FKM; Medium temperature -10...+200°C; DN 250mm; Length 68mm; Pressure range 0…16bar; Nominal flange pressure ANSI150; Flange thread UNC; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BUW6-300-CSV-L-A
Butterfly valve with hand lever; ATEX Ex II 2GD c TX; Wafer type; Length According to EN558−1R20; Body Carbon steel A216-WCB; Disc 1.4408; Shaft 1.4016; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 300mm; Length 78mm
GL116-65-W-C
Globe valve; PN40; With bellows; Body 1.4408; Seat, Cone, Stem Stainless steel 1.4401; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Rising stem; Medium temperature -10..+400°C; DN 65mm; Length 290mm; Pressure range 0...40bar; With control cone
BUW6-250-SSVS-G
Butterfly valve, aluminium manual gearbox DN250, wafer type, PN10/16/A150, 0-16bar body, disc and shaft 1.4408, sleeve FKM
BUW2-350-DSF-B
Butterfly valve, free shaft end DN350, wafer, PN10/16/A150, 0-6bar body GGG40, disc 1.4408 sleeve silicone food-grade
BULC-300-CSN-G
Butterfly valve with manual gear box; Lug type; Length According to EN558−1R20; Body Carbon steel A216-WCB Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Nominal flange pressure PN10; Medium temperature -10...+100°C; Pressure range 0...10bar; DN 300mm; Length 78mm
BUW6-300-CSV-B-A
Butterfly valve with bare shaft; ATEX Ex II 2GD c TX; Wafer type; Length According to EN558−1R20; Body Carbon steel A216-WCB; Disc 1.4408; Shaft 1.4016; Liner FKM; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+200°C; Pressure range 0...16bar; DN 300mm; Length 78mm
A1G5I2-B-200
Knife gate valve With manual gear box; Wafer type; Rising stem; Body 1.4408; Gate 1.4401; Soft sealed EPDM; Packing PTFE-Synthetic/EPDM; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+90 °C; DN 200mm; Length 60mm; Pressure range 0-10bar; Soft sealing with fixing ring and abrasion protection 1.4408
BUW4-400-DSD-B
Butterfly valve with bare shaft; Wafer type; DVGW-gas-approved; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR ; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+60°C; Pressure range 0...10bar; DN 400mm; Length 102mm
BUW6-400-DSD-B
butterfly valve with bare shaft; wafer type; DVGW-gas-approved; length according to EN558−1R20; housing ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; nominal flange pressure PN10/16/ANSI150; medium temperature -10...+60°C; DN 400mm; length 102mm; pressure range 0...16bar
GL123-80-W-C
Globe valve; PN40; Body 1.4408; Seat, Cone, Stem Stainless steel 1.4401; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Non rising stem; Medium temperature -10..+400°C; DN 80mm; Length 310mm; Pressure range 0-40bar; Control cone
GL123-65-W-AC-3C-02
globe valve; PN40; with control cone; ATEX-design; housing AISI 316; seat, cone, stem stainless steel AISI 316; seal PTFE; handwheel steel; packing gland graphite; back seal; metal sealing; non rising stem; medium temperature -10..+180°C; incl. inspection certificate EN-10204-3.1; for material, pressure, function and tightness; DN 65mm; length 290mm; pressure range 0...40bar
BULA-300-CSN-G-A3E
Butterfly valve with manual gear box Series BULA-CSN-G-A3E; ATEX II 2GD Ex h X; Lug type; Length According to EN558−1 R20; Body Steel 1.0619 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -25...+100°C; DN 300mm; Length 78mm; Pressure range 0…16bar; Nominal flange pressure PN16; Notch impact test -29°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULA-400-DSE-B
butterfly valve with bare shaft; lug type; length according to EN558−1R20; housing ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner EPDM; medium temperature -10...+130°C; DN 400mm; length 102mm; pressure range 0…16bar; flange PN16
BUW9-200-SSIQ-G-A3C
Butterfly valve with manual gear box; Wafer type; ATEX Ex II 2GD c TX; Length According to EN558−1R20; Body, Disc 1.4408; Shaft 1.4542; Seat Inconel 625; Medium temperature -10...+425°C; Pressure range 0...25bar; DN 200mm; Length 61mm; Flange PN10/16/25/ANSI150; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
GL123-80-W-AC-3C
Globe valve; PN40; Body 1.4408; Seat, Cone, Stem Stainless steel 1.4401; Handwheel Steel; Packing gland Graphite; Back seal; Metal sealing; Non rising stem; Medium temperature -10..+400°C; ATEX-design; DN 80mm; Length 310mm; Pressure range 0-40bar; With Control cone; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
BUW6-400-DPS-G
Butterfly valve with manual gear box; Wafer type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc Ductile iron EN-GJS-400-15, Shaft 1.4016; Liner Silicone; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+190°C; Pressure range 0...16bar; DN 400mm; Length 102mm
