Special armatures

STASTO Allgemeine Preisliste (EUR)
CVFV-P-50-NC-010
2/2-way coaxial valve; DN50, PN40; 0...40bar; 24VDC; NC; externally controlled; body: steel nickel plated; medium: nitrogen/helium; incl. 5/2-way pilot valve Festo; incl. 2 inductive limit switches OPEN/CLOSED; incl. inspection certificate 3.1; SIL3; special version
CVFE-P-25-NC-010
2/2-way coaxial valve; externally controlled; flange DN25; PN40; 0...40bar; 24VDC; NC; body: steel nickel plated; medium: nitrogen/helium; incl. 5/2-way pilot valve; incl.LED ;incl. inspection certificate 3.1; incl. 2 inductive limit switches OPEN/CLOSED (I.); helium leak rate test; SIL3; special version
CVFV-P-80-NC-008
2/2-way coaxial valve; Externally controlled; Flange PN40, DN80; 0...40bar; 24VDC; NC; Body: Steel nickel plated; Medium: Nitrogen/Helium; Incl. 5/2-way pilot valve; Incl. 2 inductive limit switches OPEN/CLOSED P&F NJ2-12GK-SN-10M; Incl. inspection certificate 3.1; CE-label CE0036; SIL3-Approval 968/FSP 2969.00/25; Special version
CVFE-P-32-NC-006
2/2-way coaxial valve; Externally controlled; Flange PN40; 0...40bar; 24VDC, DN32; NC; Body: Steel nickel plated; Medium: Nitrogen/Helium; Incl. 5/2-way pilot valve; CE0036-Mark; Incl. 2 inductive limit switches OPEN/CLOSED P&F NJ2-12GK-SN-10M; Incl. inspection certificate 3.1; SIL3-Approval 968/FSP 2969.00/25; Special version
CVFV-P-50-NC-011
2/2-way coaxial valve; Externally controlled; Flange PN40 DN50; 0...40bar; 24VDC; NC; Body: Steel nickel plated; Medium: Nitrogen/Helium; Incl. 5/2-way pilot valve; Incl. 2 inductive limit switches OPEN/CLOSED P&F NJ2-12GK-SN-10M; Incl. inspection certificate 3.1; CE-Mark; SIL3-Approval 968/FSP 2969.00/25; Special version
CVFE-P-25-NC-011
2/2-way coaxial valve; Externally controlled; Flange PN40 DN25; 0...40bar; 24VDC; NC; Body: Steel nickel plated; Medium: Nitrogen/Helium 60°C; Incl. 5/2-way pilot valve; ;Incl. inspection certificate 3.1; Incl. 2 inductive limit switches OPEN/CLOSED P&F NJ2-12GK-SN-10M; Helium leak rate test; SIL3-Approval 968/FSP 2969.00/25; Special version
SG06-15-UWC80-03
control valve type SG06, DN15; PN10/40; NC; material: 1.0570; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 0,44 (10%); characteristic linear; actuator diameter 80mm; digital positioner; 4-wire; ATEX Zone 22 (dust D, II category 3)
224983
Hexagon socket screw + o-ring for coax valve FMX-2
SG06-15-WWC80-09
control valve type SG06, DN15; PN10/40; NC; material: AISI 316; fixed disc AISI 316Ti coated; sliding disc carbon material; carrier with Silicone adhesive glued; kvs-value 1,4 (25%); characteristic linear; actuator diameter 80mm; digital positioner; 4-wire; Positioner setting: for very fast control (hysteresis 0,6%); special version: Remote positioner with wall bracket
CVTE-P-40-NC-006
2/2-way coaxial valve; externally controlled; G11/2"; 0...63bar; 24VDC, DN40; NC; body: zinc plated steel; medium: emulsion; incl. 5/2-way pilot valve; incl. LED; special version
CVF-40-NC-049
2/2-way coaxial valve; directly operated; flange PN40 DN40; 0...40bar; 230VAC; NC; body: zinc plated steel; medium: compressed air; terminal box; back pressure tight; incl. 2 inductive limit switches OPEN/CLOSED (B.); connector with cable 10m long; special seals; incl. inspection certificate 3.1; incl. material certificate; special version
CVT-10-NC-561
2/2-way coaxial valve; directly operated; G3/4"; 0...16bar; 24VDC; DN10; NC; body: brass; medium: mineral oil 20-28°C; Special seals; special version
CVTE3-10-NC-026
3/2-way-coaxial valve; externally controlled; G3/8"; 0...40bar; DN10; NC; body: brass; medium: air; special version
SG09-100-WWC1253-02
control valve type SG09, DN100; PN10/40; NC; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 77 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
SG09-150-WWC1253-02
control valve type SG09, DN150; PN10/40; NC; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 147 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
SG09-125-WWC1253-02
control valve type SG09, DN125; PN10/40; NC; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 116 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
SG09-50-WWC1253-02
control valve type SG09, DN50; PN10/40; NO; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 19 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
SG09-25-WWC1253-05
control valve type SG09, DN25; PN10/40; NC; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 5 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; feedback module 4-20mA
SG09-80-WWC1253-01
control valve type SG09, DN80; PN10/40; NO; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 35 (63%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
SG09-100-WWC1253-03
control valve type SG09, DN100; PN10/40; NO; material: AISI 316Ti/AISI 316Ti; fixed disc AISI 316Ti coated; sliding disc carbon material; kvs-value 77 (100%); characteristic equal percentage; diaphragm actuator 125cm²; digital positioner; 2-wire; 4-20mA; ATEX II 2G Ex ia IIC T4 Gb, IP 65; incl. earthing connection; Version for gaseous hydrogen; feedback module 4-20mA
