Special armatures

STASTO Allgemeine Preisliste (EUR)
CVFV-50-N0-001
2/2-way coaxial valve; Externally controlled; Flange Acc. to ANSI 150 DN50; 0...16bar; NO; Body: Steel nickel plated; Medium: Hydrogen 80°C; Special seals; Back pressure tight; Incl. mounting bracket; ATEX Ex II 2G Ex h IIC T-20°C...+80°C Gb X; Ex II 2D Ex h IIIC T-20°C...+80°C Db X; Incl. 2 inductive NAMUR limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Special valve testing; Special version
CVPSP23-15-005
Coax-Pressure regulating valve; Externally controlled; Proportional
3/2-way; G3/4", Continuous pressure control by electric setpoint input; With spring return, 5...100bar, 24VDC, DN15, Body: Aluminum, Medium: Water 40°C; Incl. Mounting bracket; Special version
CVPSP2-3-15-003
3/2-way-Pressure regulating valve; G3/4"; 5…100bar; 24VDC; DN15; Externally controlled; Continuous pressure control by electric setpoint input 0-10V; Body: Aluminum; Medium: Air; Incl. mounting bracket; Special version
CVPSP23-15-001
3/2-way-Pressure regulating valve; G3/4"; Continuous pressure control by electric setpoint input; Externally controlled; With spring return; 5-100bar; 24VDC; DN15; Body: Aluminum; Medium: Emulsion/Oil; Incl. Mounting bracket; Special version
SPP-2-15DR-529261
3/2-way pressure regulating valve, G 3/4" infinitely variable pressure regulation via electrical setpoint specification pilot-operated with spring return 5-100bar, 24VDC, DN 15 Body: aluminium, Medium: emulsion/oil incl. mounting bracket
CVF-40-N0-005
2/2-way coaxial valve; Directly operated; Flange DN40 PN16; 0...16bar; 230VAC; NO; Body: Stainless steel; Medium: Mineral oil ISO VG46; Special seals; ATEX Ex II 3G Ex nA IIC T3 Ta -20...+80°C Gc / Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc IP65 And CE Ex II 3 GD c T4 ; Special version
CVF-40-N0-006
2/2-way coaxial valve; Directly operated; Flange DN40 PN16; 0...16bar; 230VAC; NO; Body: Stainless steel; Medium: Hydrogen; Special seals; ATEX Ex II 3G Ex nA IIC T3 Ta -20...+80°C Gc / Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc IP65 And CE Ex II 3 GD c T4 ; Special version
CVF-40-N0-008
2/2-way coaxial valve; Directly operated; Flange DN40 PN16; 0...16bar; 230VAC; NO; Body: Stainless steel; Medium: Hydrogen/Nitrogen; Special seals; ATEX Ex II 3G Ex nA IIC T3 Ta -20...+80°C Gc / Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc IP65 And CE Ex II 3 GD c T4 ; Special version
CVCDH3-P-15-NC-003
3/2-way high pressure valve; G1/2"; 0...500bar; 24VDC; DN15; NC; Externally controlled; Body: Stainless steel; Medium: Demineralized water; Incl. 5/2-way pilot valve; With exhaust throttle; Incl. LED; Special version
SG09-25-UWN1253-01
Control valve Type SG09; DN25; ANSI600; NC; Material: Zinc plated steel; Fixed disc STN2; Sliding disc STN2; Kvs-value 0,14 (1%); Characteristic Linear; Diaphragm actuator 125cm², Incl. Coupler
MK40NC-555035
2/2-way coaxial valve; G11/2"; 0…63bar; 220VDC; DN40; NC; Directly operated; Body: Stainless steel; Medium: Water; Incl. LED; Incl. 1 inductive limit switch (B) For closed-position; Special version
4MB-5-VMK15NC-548041
4-fold Module block Consists of 4 Pcs VMK15NC; Module connection And Outlets 1/2"; 0...16bar; 24VDC; DN15; NC;Externally controlled; Body: Brass; Medium: Emulsion; Incl. 5/2-way pilot valve; Coil with connection M12x1-VDMA; Incl. 2 Mounting bracket; With additional thread In End plate (G1") With Plug screw; Special version
4008347
GS1 functional unit complete, DN100 STN2, form A, LIN.100%, KV154
4008568
GS1 functional unit complete, DN100 STN2, form B, LIN.100%, KV154
SG03-80-UWC80-01
Sliding gate-shut off valve Type SG03, DN80; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 92 (100%); Piston actuator 80mm; Differential pressure Max. 14Bar; Incl. Electrical position indicator with 2 microswitches
CVF-40-NC-035
2/2-way coaxial valve; Directly operated; Flange DN40; PN40; 0...40bar; 24VDC; NC; Body: Stainless steel; Medium: Demineralized water; Special seals; Incl. LED; Mounting bracket; Incl. inspection certificate 3.1; Test report 2.1; Special version
CVCRQ-20-009
Coax-Control valve;Directly operated; G1"; 0...63bar; DN20; 24VDC; Setpoint value input 0...10V; Body: Brass; Medium: Emulsion; Incl. Mounting bracket; Special version
FK65NC-546581
2/2-way coaxial valve, DN 65, PN 16 0-16 bar, 24VDC, NC, direct-acting body: aluminium, medium: water incl. LED
SG08-15-WWNECB-02
Control valve with electrical actuator Type SG08; DN15; PN10/40; Body: Stainless steel AISI 316, Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 4 (100%); Characteristic linear; Safety position NC; Voltage 90-260VAC; Control actuator CA260C; Setpoint value input 4-20mA; Position feedback 4-20 mA; 2 Limit switch; Operating time 12,5s
SG09-32-UWN1253-01
Control valve Type SG09; DN32; ANSI600; NC; Material: Zinc plated steel; Fixed disc STN2; Sliding disc STN2; Kvs-value 10 (63%); Characteristic Linear; Diaphragm actuator 125cm², Incl. Coupler
