Special armatures

STASTO Allgemeine Preisliste (EUR)
CVTE-15-NC-047
2/2-way coaxial valve; G1/2"; 0...100bar; DN15; NC; externally controlled; body: brass; medium: compressed air/nitrogen/forming gas; incl. 2 inductive limit switches OPEN/CLOSED (B); vacuum-test with certificate; incl. mounting bracket; leakage port; Special grease Krytox; namur control port; ; Pressure lubrication head; length 219mm; leakage port M5x1; sealing surface min. ∅12mm; leakage rate 10-6 mbar x l/s; special version
CVFV-P-40-NC-002
2/2-way coaxial valve; DN40; PN16; 0...16bar; 24VDC; NC; Externally controlled; Body: Zinc plated steel; Medium: Rolling oil; Incl. 5/2-way pilot valve; Incl. LED; Special seals; Special version
CVT-25-N0-018
2/2-way coaxial valve; Directly operated; G11/2"; 0...63bar; 24VDC; DN25; NO; Body: Brass; Medium: Hydraulic oil; Special seals; Incl. 1 inductive limit switch Position CLOSED (I.); Special version
ECDH10N0-522049
3/2-way coaxial valve, G 3/8" 0-150 bar, 230VAC, DN 10, NO, direct-acting Body: brass, Medium: water with additive incl. terminal box and special seals
CVTEH-15-NC-001
2/2-way coaxial valve; G1/2"; 0…200bar; DN15; NC; Externally controlled; Body: Zinc plated steel; Medium: Compressed air; Incl. 2 inductive limit switches OPEN/CLOSED (I.); Special version
CVCDH-10-NC-003
2/2-way coaxial valve; G3/8"; 0…500bar; DN10; NC; Externally controlled; Body: Brass; Medium: Helium/Nitrogen; Special version
CVCDH-10-NC-006
Coax-2/2-way-lateral valve; Externally controlled G3/8"; 0...500bar; DN10; NC; Body: Brass; Medium: Helium; Special seals; Control pressure 4…8bar; Special version
CVFE-15-NC-006
2/2-way coaxial valve; Externally controlled; 0...16bar; 24VDC; NC; Stainless steel; DN15; Flange ANSI-RF 150 lb; Medium Air; Incl. 5/2-way pilot valve; Incl. LED; Special flanges; Special version
PCDH10N0-536948
2/2-way cartridge valve; G3/8"; 0...500bar; DN10; NO; Externally controlled; Body: Brass; Medium: Helium; Special seals; Control pressure 4…8bar; Special version
CVF-20-N0-005
2/2-way coaxial valve; Directly operated; Flange DN20 PN40; 0...40bar; 24VDC; NO; Body: Zinc plated steel; Medium: Methane; Terminal box; Incl. 2 mechanical limit switches; Mounting bracket; Special seals; Special version
5-VFK20NC-20038-03
2/2-way coaxial valve, DN20, PN40 0-40 bar, 220VAC, NC, pilot-operated Body: zinc-plated steel, Medium: heating oil S 140°C incl. 5/2-way Namur pilot valve (mounted separately), LED 2 mechanical limit switches (changeover) and special seals
CVT-40-NC-039
2/2-way coaxial valve; Directly operated; G2"; 0…16bar; 24VAC; DN40; NC; Body: Brass; Medium: Dirty water; Incl. special seals; Special version
SG03-25-UWC80
Sliding gate-shut off valve Type SG03, DN25; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (100%); Characteristic linear; Piston actuator 80mm
VSV-M50NC-71391
2/2-way coaxial valve, 2" 0-16bar, DN50, NC, pilot-operated Body aluminium, Medium: emulsion/oil Special seals, flushing bore, valve seat in the block
CVT-15-N0-036
2/2-way coaxial valve; Directly operated; G1/2"; 0...40bar; 24VDC; DN15; NO; Body: Stainless steel; Medium; Natural gas/Heating oil 80°C; Special seals; Terminal box; Inspection certificate 3.1; UL-Approval; ATEX CE Ex nA II T3 / CE Ex tc IIIC T195°C And Ex II 3G Ex h IIC T3 Gc / Ex II 3D Ex h IIIC T195°C Dc; Special version
SG04-40-UWF50
Sliding gate-shut off valve Pneumatically operated Type SG04, DN40; PN10/40; NC; Body: Zinc plated steel, Fixed disc 1.4571 Coated; Sliding disc SFC; Kvs-value 26 (100%); Characteristic linear; Piston actuator 50mm
MK15NC-546914
2/2-way coaxial valve, G 1/2" 0-16 bar, 230VAC, ATEX, DN 15, NC, direct-acting Body: brass, Medium: propane/butane/nitrogen special seals, flow in both directions ATEX II 2 G Eex me II T4 and II 2 D IP 65 T 130°C incl. 2 inductive NAMUR limit switches OPEN/CLOSED incl. inspection certificate 3.1
CVTE-20-NC-004
2/2-way coaxial valve; G1/14"; 0...100bar; DN20; NC; Externally controlled; Body: Stainless steel; Medium: Water; Special version
MK32DRNC-545641
3/2-way-coaxial valve; G11/2"; 0...16bar; 24VDC; DN32; NC; Directly operated; Body: Zinc plated steel; Medium: Air; Vacuum-test with certificate; Special version
CVTE-15-NC-046
2/2-way coaxial valve; Externally controlled; 1/2"NPT; 0...40bar; DN15; NC; Body: Stainless steel; Medium: Hydrogen Gaseous; Special seals; Incl. certificate for vacuum; Incl. inspection certificate 3.1; Incl. 1 inductive NAMUR limit switch CLOSED (B.); ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb; Ex II 2D Ex h IIIC T-20°C...+70°C Db; Special version
