Special armatures

STASTO Allgemeine Preisliste (EUR)
SG09-200-WWC2503-01
Control valve Type SG09, DN200; PN16; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 560 (100%); Characteristic Linear; Diaphragm actuator 250cm²; Digital positioner; 4-wire; 4-20mA; Feedback module RM5; 4-20mA
BS09-250-P-D0
Ball sector valve Pneumatically double acting; Wafer type; DN250; PN16; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring PEEK; Seals PTFE/O-ring Silicone PFA-Coated; KVS 2220 (100%); Medium temperature -60...+220°C; Actuator PAD140-H
BS01-250-V-D0-01
Ball sector valve; Wafer type; DN250; PN16; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring Stellite; Seals made of FKM; KVS 2220 (100%); Medium temperature -15…+200°C; Incl. Pneumatic actuator Double acting PAD160
CVFEH3-50-NC-002
3/2-way-coaxial valve; Externally controlled; Flange DN50; ANSI1500; 0...200bar; NC; Body: Stainless steel; Medium: Demineralized water; Mounting bracket; Incl. 1 inductive limit switch CLOSED (B.); Incl. inspection certificate 3.1; Special version
BS09-250-P-B
Ball sector valve; Wafer type; DN250; PN16; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring PEEK; Seals PTFE/O-ring Silicone PFA-Coated; KVS 2220 (100%); Medium temperature -60...+220°C; Bare shaft; Mounting flange F25; Square 27mm
SG13-250-UWCECC-01
Control valve Type SG13, DN250; PN16; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 910 (100%); Characteristic linear; Safety position NO; Control actuator 5,0 kN; 100-240V50/60Hz; Setpoint value input 4-20mA; Position feedback 4-20 mA; 2 Limit switch
BS08-250-T-AB
ball sector valve; wafer type; DN250; PN16; housing AISI 316/AISI 316L; ball sector AISI 316 hard chrome plated/lapped surface; seat ring stellite; seals PTFE/FKM; KVS 2220 (100%); medium temperature -15...+200°C;; with electric control actuator PSQ-AMS; voltage 230V50/60Hz; control signal 0/4-20mA respectively 0/2-10V; protection class IP67; visual position indicator; with manual emergency override; incl. position feedback 0/4-20mA respectively 0/2-10V
9052939
3/2-way-coaxial valve; G3/4"; 0...40bar; DN20; Externally controlled
CVFV3-P-150-N0-001
3/2-way-coaxial valve; Externally controlled; DN150, PN16; 0...16bar; 24VDC; NO; Body: Stainless steel; Medium: Water; Incl. 5/2-way pilot valve; Incl. LED; Incl. 2 inductive limit switches OPEN/CLOSED (I); Special version
SG09-250-WWC2503-01
Control valve Type SG09; DN250; PN16; NC; Material: Stainless steel 1.4581 / 1.4571; Fixed disc Stainless steel AISI 316Ti; Sliding disc Carbon; Kvs-value 910 (100%); Characteristic Linear; Diaphragm actuator 250cm²; Digital positioner; 4-wire; 4-20mA
SG09-250-WWC2503-02
Control valve Type SG09; DN250; PN16; NO; Spring opened; Material: Stainless steel 1.4581 / 1.4571; Fixed disc Stainless steel AISI 316Ti; Sliding disc Carbon; Kvs-value 910 (100%); Characteristic Linear; Diaphragm actuator 250cm²; Digital positioner; 4-wire; 4-20mA
54018-A
Sealing body Close Valve MK32, FK32, MK40, FK40; Material 1.4104
58375
Hex socket screw for K10 for mounting the mounting bracket for K10 Scope of supply: 1 pair
5MB-MK10NC-525517
5-way module consisting of: 4x2/2-way coaxial valve, G 3/4" 1x module with blank cover with thread G 1/4" 0-16 bar, 24VDC, DN 10, NC, direct-acting body: brass, medium: rolling oil module: aluminium, incl. LED, special seals mounting bracket and additional thread in end cover G 1/2", back-pressure tight (only 3 valves) 1 valve with distribution function
5-MB-VMK10NC-543801
5-way module block consisting of 5 pcs. VMK10NC, 1/2", 0-40 bar, NC, pilot-operated module: aluminium, valve: brass medium: helium/air, incl. 5 pcs. inductive limit switches and 2 pcs. mounting bracket, valves rotated 180°
5-VFK15NC-519102
2/2-way coaxial valve, DN15, PN40 0-40 bar, 24VDC, NC, pilot-operated Body: nickel-plated steel, Medium: nitrogen/helium incl. 5/2-way pilot valve Festo, LED, 2 inductive limit switches and inspection certificate 3.1
988CAP
Pneumatic Distributor Close Positioner R99P
9MBMK10NC-544768
9-way manifold block consisting of 9 pcs. MK10NC, module connection 1" outlet 1/4", 0-40 bar, NC, 24VDC, direct-acting module: aluminium anodised, valve: brass medium: contaminated water incl. 1 pc. end cover aluminium anodised
9-MB-VMK10NC-543459
9-way manifold block consisting of 9 pcs. VMK10NC, module connection 1" outlet 3/8", 0-64 bar, NC, externally piloted module: aluminium, valve: brass medium: helium, nitrogen, vacuum incl. 1 pc. end cover with additional thread
9-MB-VMK10-NC/N0-529820
9-way manifold block consisting of 6 pcs. VMK10NC-70663, G 3/8" 0-64 bar, DN 10, NC, externally piloted body brass, medium: helium/nitrogen/vacuum 3 pcs. VMK10NO-70664, G 3/8" 0-64 bar, DN 10, NO, externally piloted body brass, medium: helium/nitrogen/vacuum
