Special armatures

STASTO Allgemeine Preisliste (EUR)
SEC03-32-ST80-02
Flange-control valve; NC; Material: 1.4408, Seal PTFE; Flange PN40; DN 32mm; Kvs-value 16 (100%), Characteristic linear, Actuator diameter 80mm; Medium temperature -30...+170°C; Length 180mm; Operating pressure 0-10bar; Digital positioner; 4-wire; 4-20mA; Position indicator 4-20mA; 2 Limit switch 24VAC/DC, Max. 70mA
SG06-15-WWN80-01
Control valve Type SG06, DN15; PN10/40; NC; Material: 1.4408; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 0,71 (16%); Characteristic Linear; Actuator diameter 80mm; Digital positioner; 4-wire
CVF-40-N0-002
2/2-way coaxial valve; PN16; 0...16bar; 24VDC; DN40; NO; Directly operated; Body: Steel nickel plated; Medium: Hydrogen 80°C; Special seals; Terminal box Cable gland M20x1,5; Back pressure tight; Incl. mounting bracket; ATEX Ex nA IIC T3 Ta -20…+80°C Gc And Ex tc IIIC T195°C Ta -20…+80°C Dc IP65; Incl. 2 inductive NAMUR limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Special version
CVF-25-NC-022
2/2-way coaxial valve; Directly operated; Flange DN25 PN100; 0...100bar; 230VAC; DN25; NC; Body: Stainless steel; Medium: Demineralized water +60°C; Incl. LED; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Special version
SG19-25-UWC80-01
Control valve Type SG19, DN25; ANSI150; NC; Material: 1.0570/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (100%); Characteristic Linear; Piston actuator 80mm; Digital positioner; 4-wire; 4-20mA
SG19-25-UWC80-02
Control valve Type SG19, DN25; ANSI150; NO; Material: 1.0570/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (100%); Characteristic Linear; Piston actuator 80mm; Digital positioner; 4-wire; 4-20mA
CVF-65-NC-006
2/2-way coaxial valve; Directly operated; Flange PN16 DN65; 0...16bar; 24VDC; NC; Body: Zinc plated steel; Medium: Hydrogen; Special seals; Incl. mounting bracket; Special version
BS08-40-V-L
Ball sector valve; Wafer type; DN40; PN40; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring Stellite; Seals made of FKM; KVS 64 (100%); Medium temperature -15...+200°C; Actuation Hand lever
SG08-40-WWCECB-01
Control valve with electrical actuator Type SG08; DN40; PN10/40; Body: Stainless steel AISI 316, Fixed disc 1.4571; Sliding disc Carbon material; Kvs-value 26 (100%); Characteristic linear; Safety position NO; Voltage 90-260VAC; Control actuator CA260C; Setpoint value input 4-20mA; Position feedback 4-20 mA; 2 Limit switch; No voltage return
SEC03-040-ST80-001
Flange-control valve Type SEC03; DN40; PN40; Material: 1.4408, Seal: PTFE; Kvs-value 22 (100%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA
SG06-15-WWC80-07
Control valve Type SG06, DN15; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 2,6 (63%); Characteristic Linear; Actuator diameter 80mm; Digital positioner; 2-wire
CVF-40-NC-029
2/2-way coaxial valve; Directly operated; Flange DN40; PN16; 0...16bar; 24VDC; NC; Body: Stainless steel; Medium: Nitrogen Gaseous; Special seals; Terminal box; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Material test certificate; ATEX CE Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc; CE Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc; Special version
CVF-40-NC-027
2/2-way coaxial valve; Directly operated; PN16; 0…16bar; 220VDC; DN40; NC; Body: Stainless steel; Medium: Hydrogen Gaseous; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Vacuum-test with certificate; ATEX CE Ex nA II T3 / CE Ex tc IIIC T195°C; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc
8044-4066962
8044/015VE0101M----5-ZC GS control valve type 8044 with I/P positioner 4-20mA, 4-wire housing stainless steel, DN15, PN10-40 disc pairing carbon/stainless steel kv value 0,04, linear 1% fail-safe position - spring closes
8044-GS1-025-4072752
025VE0001M--S---ZR GS1 control valve, DN25, PN10-40, NC body carbon steel, moving disc SFC, actuator D80 KVS= 11 (100%), linear, incl. digital positioner 8049-2 wire, 0/4-20mA
SG06-50-WWC80-02
Control valve Type SG06; DN50; PN10/40; NC; Material: 1.4408, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 10 (20%), Characteristic linear, Actuator diameter 80mm; Actuator Made of stainless steel; Analog P/P-positioner
CVF-50-N0-012
2/2-way coaxial valve; Directly operated; Flange PN16 DN50; 0...16bar; 24VDC; NO; Body: Steel nickel plated; Medium: Hydrogen/Argon -20...+80°C;Special seals; Incl. mounting bracket; ATEX II 3 GD / Ex nA IIC T3 / Ex tc IIIC T195°C; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. test report 2.2; Incl. inspection certificate 3.1; Special version
SG06-50-UWC80-01
Control valve Type SG06; DN50; PN10/40; NC; Material: Steel/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 45 (100%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA
SG07-15-UWC1254-05
Control valve Type SG07, DN15; PN10/40; NC; Body: Carbon steel; Fixed disc 1.4571; Sliding disc Carbon material; Kvs-value 4 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; Input signal 4-20 mA
SG06-20-WWC80-01
Control valve Type SG06, DN20; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 6,4 (100%); Characteristic Linear; Actuator diameter 80mm; Digital positioner; 2-wire
