STASTO Solenoid valves: Reliable solutions for liquids and gases

Armatures

Solenoid valves for liquids and gases

21W5KV350-Y1220-240V/50-60HZ-2

21W5KV350
2/2-way solenoid valve Series 21W; Pilot-operated; NC; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+120°C; Standard coil BDA; Connector size 32mm; G 11/4"; DN 35mm; Pressure AC/DC 0,2-10bar; Length 144mm
Y1220-240V/50-60HZ-2
Mounted coil; Type Y1, ATEX- II 2G Exmb IIC T4/ II 2D Exmb tb IIIC T130°C; Cable length 3m; Voltage 220-240V/50-60Hz; Medium temperature Max. 80°C

SL077-12-22-01

2/2-way solenoid valve; Combined operated; Connection G1/2", DN13,5; Pressure 0-40bar; Body 1.4581; Seal PTFE; Medium temperature -40…+80°C; NC; 230V/50-60Hz; Mounting position only with vertical solenoid

SL021-FL-1,5-C03-01

3/2-way solenoid valve; Directly operated; NC; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+120°C; Coil BDV; Voltage 24VDC; Connector size 32mm; Flange; DN 1,5/2,5mm; Pressure AC/DC 0...15bar; Length 40mm

21JP1R1V23-T0-LBA05024CS-C002-31-6

21JP1R1V23-T0
2/2-way solenoid valve; Directly operated; NC; Body PPS; Tube Stainless steel; Seal FKM; Medium temperature -10...+120°C; Standard coil LBA; Connector size 22mm; G 1/8"; DN 2,3mm; Pressure AC 0-15bar; Pressure DC 0-8bar; Length 34mm; NSF-certificate
LBA05024CS
Coil Type LBA; Connector size 22mm; Voltage 24VDC
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

SL078-12-V-03-01

2/2-way solenoid valve; Combined operated; NO; Body Brass; Medium temperature 0...+60°C; including solenoid coil and terminal box; Seal FKM; G 1/2"; DN 15mm; Pressure 0...16bar; Length 67mm; Voltage 24VDC; ATEX Ex II 2G Ex e mb IIC T4 Gb And Ex II 2D Ex mb tb IIIC T130°C Db

SL002-14-2-E-CS03

2/2-way solenoid valve series SL002; directly operated; NC; body brass; tube stainless steel one-piece; seal EPDM; connector size 32mm; G 1/4"; DN 2mm; pressure 0...16bar; medium temperature -10...+140°C; length 40mm; coil BDV; voltage 24VDC; incl. connector

SL002-18-2-E

2/2-way solenoid valve; directly operated; NC; body brass; tube stainless steel one-piece; seal EPDM; medium temperature -10...+140°C; standard coil BDA; connector size 32mm; G 1/8"; DN 2mm; pressure AC 0-22bar; pressure DC 0-16bar; length 40mm

21HT4K0Y160-UDA

2/2-way solenoid valve Series 21H..K0Y; Combined operated; NC; Body Brass; Stainless steel tube; Seal NBR; Medium temperature -10...+90°C; Connector size 32mm; G 1/2"; DN 16mm; Pressure AC 0-14bar; Pressure DC 0-11bar; Length 70mm; Standard coil UDA

21HT5K0V160-UDA

2/2-way solenoid valve Series 21H..K0V; Combined operated; NC; Body Brass; Stainless steel tube; Seal FKM; Connector size 32mm; G 3/4"; DN 16mm; Pressure AC 0-14bar; Pressure DC 0-11bar; Medium -10/+140°C; Length 70mm; Standard coil UDA

21H8KV120-BDA08024CS-C003-32-LV-2

21H8KV120
2/2-way solenoid valve; Pilot-operated; NC; Body Brass; Tube Stainless steel Hard soldered; Seal FKM; Medium temperature -10…+120°C; Standard coil BDA; Connector size 32mm; G 1/2"; DN 12mm; Pressure AC 0,1-20bar; Pressure DC 0,1-10bar; Length 50mm
BDA08024CS
Coil Type BDA; Standard; Connector size 32mm; Voltage 24VDC
C003-32-LV-2
Connector; Connector size 32mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC

GDV14024C3

Coil ATEX-II 3G Ex nA IIC T3 Gc/ II 3D Ex tc IIIC T200°C Dc IP65; Voltage 24VDC; 32mm

GDV14230A3

Coil ATEX-II 3G Ex nA IIC T3 Gc/ II 3D Ex tc IIIC T200°C Dc IP65; Voltage 230V/50Hz; 240V/60Hz; 32mm

21HT6K0Y250

2/2-way solenoid valve Series 21H..K0Y; Combined operated; NC; Body Brass; Stainless steel tube; Seal NBR; Medium temperature -10...+90°C; Connector size 32mm; G 1"; DN 25mm; Pressure AC 0-8bar; Length 104mm; Standard coil BDA

21HT6K0Y250-BDA08012AS-C003-32-6

21HT6K0Y250
2/2-way solenoid valve Series 21H..K0Y; Combined operated; NC; Body Brass; Stainless steel tube; Seal NBR; Medium temperature -10...+90°C; Connector size 32mm; G 1"; DN 25mm; Pressure AC 0-8bar; Length 104mm; Standard coil BDA
BDA08012AS
Coil Type BDA; Standard; Connector size 32mm; Voltage 12V/50Hz
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC

SL057-20-03-03

2/2-way solenoid valve; Combined operated; NC; Body Brass; Medium temperature -10...+80°C; With adjustable closing delay; Incl. coil; Terminal box; Seal NBR; G 2"; DN 50mm; Pressure 0...16bar; Length 168mm; Voltage 24VDC; SIL approval; Mounting position only with vertical solenoid

SL057-12-03-06

2/2-way solenoid valve; Combined operated; NC; Body Brass; Medium temperature -10...+80°C; Seal NBR; G 1/2"; DN 13,5mm; Pressure 0...16bar; Length 67mm; Incl. coil and connector; Voltage 24VDC; Mounting position only with vertical solenoid; SIL approval;

21L2K1V55-GDV-GDV14024CY-C003-32-6

21L2K1V55-GDV
2/2-way solenoid valve Series 21L; Directly operated; NC; Body Stainless steel 1.4401; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+140°C; Standard coil GDV; Connector size 32mm; G 1/4"; DN 5,5mm; Pressure AC 0-10bar; Pressure DC 0-5bar; Length 39mm
GDV14024CY
Coil Type GDV/GDH; For higher pressures/temperatures; Connector size 32mm; Voltage 24VDC; Approval CSA/UL/VDE
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC

SC-SL102-38/10

Replacement spring for Solenoid valve SL102-38/10
