NSF-approved; Body Fibre-glass-reinforced polyamide Grivory GV-5 FWA; Seals EPDM-FDA; Maximum inlet pressure 15bar; Medium temperature +4…+60°C; Flow at Δp=0,8bar 10l/min
Pressure regulator fixed set Series PR64 -
Body Brass; Spring cover Polyamide; Seals NBR; Max. Inlet pressure 40bar; Operating pressure range 1...10bar; Medium temperature 0...70°CPressure regulator Series PR01
-
Body Brass; Fine screen Stainless steel; Spring cover, Screen cup Polyamide; Seals NBR/EPDM; Mesh size 0,5mm; Max. Inlet pressure 30bar; Operating pressure range 1,5...6bar; Medium temperature -10…+70°C
Pressure regulator Series PR02/PR10 -
Body Bronze; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 25bar; Operating pressure range 0,5...2bar; Medium temperature -20...+120°C
Pressure regulator Series PR03...0.5/2 -
Without relieving; Body Bronze; Maximum inlet pressure 60bar
Pressure regulator Series PR40 -
Body Bronze; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 40bar; Operating pressure range 5...15bar; Medium temperature -20…+95°C
Pressure regulator Series PR03…5/15 -
Body Bronze; Fine screen Stainless steel; Spring cover, Seals FKM; Max. Inlet pressure 40bar; Operating pressure range 1...8bar; Medium temperature -10…+120°C
Pressure regulator Series PR03-V -
Body Bronze; Flange PN16; Fine screen Stainless steel; Seals EPDM; Max. Inlet pressure 16bar; Medium temperature -20…+120°C
Flange pressure regulator Series PR04 -
Body Bronze; Flange PN16; Fine screen Stainless steel; Seals EPDM; Max. Inlet pressure 16bar; Operating pressure range 5...15bar; Medium temperature -20…+95°CFlange pressure regulator Series PR04...5/15
-
Body Ductile iron EN-GJS-400-15; Seals EPDM; Flange PN16; Max. Inlet pressure 16bar; Operating pressure range 0,5…2bar; Medium temperature -10…+60°C
Flange pressure regulator Series PR21 -
Body Bronze; Flange PN40; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 40bar; Operating pressure range 1...8bar; Medium temperature -20…+120°C
Flange pressure regulator Series PR04-PN40 -
Body 1.4408; Seals FKM; Medium temperature -10…+120°C
Pressure regulator Series PR08 -
Body 1.4408; Seals FKM; Maximum inlet pressure 40bar; Operating pressure range 5...15bar; Medium temperature -10…+95°C
Pressure regulator Series PR08...5/15 -
Body 1.4301; 11/2"...2" 1.4571; Inner parts 1.4571; Medium temperature -20…+200°C
Pressure regulator Series PR09 -
Body 1.4408; Flange PN40; Fine screen Stainless steel; Seals FKM; Medium temperature -10…+120°CFlange pressure regulator Series PR12
-
Body 1.4408; Flange PN40; Fine screen Stainless steel; Seals FKM; Operating pressure range 5...15bar; Medium temperature -10…+95°CFlange pressure regulator Series PR12...5/15
Pressure regulator
Pressure regulator Series PR03-V
Body Bronze; Fine screen Stainless steel; Spring cover, Seals FKM; Max. Inlet pressure 40bar; Operating pressure range 1...8bar; Medium temperature -10…+120°C
| Male thread | Mesh size | Outlet pressure | Inlet pressure | Medium temperature | Suitable manometer | Type | Sequence |
|---|---|---|---|---|---|---|---|
| R 1 1/4" | 0,6 mm | 1...8 bar | Max. 40 bar | -10...+120 °C | MA001-63R-10-D | PR03-114-1/8-V | 33520003 |
| R 1 1/2" | 0,75 mm | 1...8 bar | Max. 40 bar | -10...+120 °C | MA001-63R-10-D | PR03-112-1/8-V | 33520004 |
| Male thread | Mesh size | Outlet pressure | Inlet pressure | Medium temperature | Suitable manometer | Type |
|---|---|---|---|---|---|---|
| R 2" | 0,75 mm | 1...8 bar | Max. 40 bar | -10...+120 °C | MA001-63R-10-D | PR03-20-1/8-V |
| Male thread | Mesh size | Outlet pressure | Inlet pressure | Suitable manometer | Design | Type | Sequence |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | PR40-12-0,5/15-0 | 33520007 |
| - | - | - | - | - | - | PR40-12-0,5/15-01 | 33520008 |
| - | - | - | - | - | - | PR40-12-0,5/15-1 | 33520009 |
| - | - | - | - | - | - | PR40-12-0,5/15-E | 33520010 |
| - | - | - | - | - | - | PR40-12-5/30-E | 33520011 |
| - | - | - | - | - | - | PR40-12-10/50-E | 33520012 |
| - | - | - | - | - | - | PR40-14-0,5/15-E | 33520014 |
| - | - | - | - | - | - | PR40-14-5/30 | 33520015 |
| - | - | - | - | - | - | PR40-14-10/50-E | 33520018 |
| - | - | - | - | - | - | PR40-20-0,5/15 | 33520019 |
| - | - | - | - | - | - | PR40-20-0,5/15-E | 33520020 |
| - | - | - | - | - | - | PR40-20-5/30 | 33520021 |
| - | - | - | - | - | - | PR40-20-5/30-0 | 33520022 |
| - | - | - | - | - | - | PR40-20-5/30-E | 33520023 |
| - | - | - | - | - | - | PR40-20-10/50 | 33520024 |
| - | - | - | - | - | - | PR40-20-10/50-E | 33520025 |
