Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

Ball valve made of brass Series BA862; Full bore; Female thread; Seal PTFE; Medium temperature -20...+160°C; Turning handle Aluminum; Connection G 3/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 53mm

Ball valve made of brass Series BA862; Full bore; Female thread; Seal PTFE; Medium temperature -20...+160°C; Turning handle Aluminum; Connection G 1"; Nominal diameter 25mm; Pressure range 0-40bar; Length 63,5mm

High pressure ball valve Series BA306; Male thread according to ISO 8434-1 (DIN 2353); Body Zinc plated steel; Ball Steel; Seals POM/FPM; Medium temperature -20...+100°C; For liquids; Connection 16S/M24x1,5; Nominal diameter 13mm; Pressure range 0...500bar; Length 86mm

High pressure ball valve Series BA234; Male thread According to ISO 8434-1 (DIN 2353); Body, Ball 1.4571/1.4404; Seals POM/NBR; For hydraulic liquids; Medium temperature -30...+100°C; Connection 18L/M26x1,5; Nominal diameter 15mm; Pressure range 0...400bar; Length 82mm

BA368-25-S0-A
Flanged ball valve with pneumatic actuator Series BA368-S-A; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Body, Ball 1.4408; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Nominal diameter 25mm; Pressure range 0...40bar; Flange PN40; Length 125mm; Actuator PAS0635
ABS53-PI10
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); Actuator PAS052-270; Connection 10mm
EPC02400-1
Mounted coil Type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; Cable length 3m; Voltage 24VDC
EB0X05
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831391 - ATEX; Contact material Silber-Nickel; Material of case Plastic

Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

Flanged ball valve; ATEX II 2 G/D; Full bore; Body, Ball 1.4401; Seals PEEK/FFKM; Medium temperature -20...+250°C; Nominal diameter 25mm; Pressure range 0...40bar; Flange PN40; Length 57mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA368-25-T0-A
Flanged ball valve with pneumatic actuator Series BA368-T-A; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Body, Ball 1.4408; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Nominal diameter 25mm; Pressure range 0...40bar; Flange PN40; Length 125mm; Actuator PAS0635; Safety position NO
ABS53-PI10
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); Actuator PAS052-270; Connection 10mm
EPC02400-1
Mounted coil Type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; Cable length 3m; Voltage 24VDC
EB0X05
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831391 - ATEX; Contact material Silber-Nickel; Material of case Plastic

Seal kit for Ball valve Series BA050; DN25; PTFE-Reinforced with carbographite

High pressure ball valve Series BA804-B; Female thread; Body Steel; Ball Stainless steel; Seals FPM ; Medium temperature -20...+100°C; Connection G11/2"; Nominal diameter 40mm; Pressure range 0...420bar; Length 130mm

High pressure ball valve Series BA804-L; Male thread According to ISO 8434-1 (DIN 2353); Body Steel; Ball Stainless steel; Seals FPM ; Medium temperature -20...+100°C; Connection 38S/M52x2; Nominal diameter 32mm; Pressure range 0...420bar; Length 148mm

Hand lever made of steel Suitable to 3500; 3600-1 1/2"

High pressure ball valve Series BA236, BA646; 3-way-type; Sealing on two sides; Pressure inlet just in front; Female thread; Body Zinc plated steel; Ball Steel; Seals POM/NBR; Medium temperature -20...+100°C; For liquids; G 3/4"; Nominal diameter 20mm; Pressure range 0...315bar; Length 95mm; Ball L; Hand lever Cranked

High pressure ball valve; 3-way-type; Sealed on all sides; Female thread; Ball Stainless steel 1.4571; Seals POM/FPM; Medium temperature -20...+100°C; Connection G 3/8"; Nominal diameter 10mm; Pressure range 0-400bar; Length 115mm; Ball L; Actuation Hand lever

High pressure ball valve With locking device; Flange connection ISO 6162-1 3000psi; Body; Ball Steel; Seals POM/NBR; Medium temperature -20...+100°C; Nominal diameter 50mm; Pressure range 0...210bar; Length 232mm

Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

Flanged ball valve Series BA131; ATEX II 2 G/D c T3; Flange PN16; Full bore; Body, Ball 1.4401; Seals PTFE/EPDM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Length 46mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

Flanged ball valve Series BA131; Flange PN16; Full bore; Body, Ball 1.4401; Seals PTFE/EPDM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Length 46mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
