Ball valves - manually operated

STASTO Allgemeine Preisliste (EUR)
C3M-BA648-20-AH
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA648-25-B-AH-3C
Flanged ball valve; ATEX zone 1 and 21, TA-Luft; Flange PN40, DIN EN 1092-1, Full bore; Length According to EN558−FTF 27; Body, Ball 1.4408; Seals PTFE/FKM; Pressure range 0…40bar; Medium temperature -20…+150°C; Nominal diameter 25mm; Length 125mm; Mounting flange ISO5211 F05 Square 14mm; Incl. acceptance test certificate EN-10204-3.1; for material, pressure, function and tightness; Free of oil and grease for hydrogen
C3M-BA648-25-AH
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA648-50-B-AH-3C
Flanged ball valve; ATEX zone 1 and 21, TA-Luft; Flange PN40, DIN EN 1092-1, Full bore; Length According to EN558−FTF 27; Body, Ball 1.4408; Seals PTFE/FKM; Pressure range 0…40bar; Medium temperature -20…+150°C; Nominal diameter 50mm; Length 140mm; Mounting flange ISO5211 F07 Square 17mm; Incl. acceptance test certificate EN-10204-3.1; for material, pressure, function and tightness; Free of oil and grease for hydrogen
C3M-BA648-50-AH
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA9XX-15-L
Ball valve made of stainless steel; Butt weld ends; Body, Ball Hastelloy C276; Seals PTFE/FEPM; Medium temperature -20...+160°C; Nominal diameter 15mm; Pressure range 0-40bar; Length 160mm
BA847-12N-L-A-01
Ball valve made of stainless steel; Fire-Safe Body 1.4401; Ball 1.4401/CRC-Coated; Seals Metallic CRC/Thermiculite; Stem Nitronic-50; Medium temperature 0...+538°C; Connection 1/2"NPT; Nominal diameter 15mm; Pressure range 0...25bar; Antistatic; Fire Safe
C3M-BA062-100-A
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA062-100-L-A3C
Flanged ball valve Series BA062, BA063; ATEX II 2 G/D c T3; TA-Luft; 3-way-type; Sealing on three ports; Full bore; Flange PN16; Body, Ball Stainless steel 1.4401; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 100mm; Length 244mm; Ball L; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA925-112-B
High pressure ball valve; Female thread; Zinc plated steel; Ball stainless steel 1.4571; Seals PEEK/Special; Medium temperature -10...+250°C; G11/2"; Nominal diameter 38mm; Pressure range 0-400bar; ISO flange F05; SW17; 65Nm
BA925-20-B
High pressure ball valve; Female thread; Zinc plated steel; Ball stainless steel 1.4571; Seals PEEK/Special; Medium temperature -10...+250°C; G2"; Nominal diameter 48mm; Pressure range 0-400bar; ISO flange F05; SW17; 80Nm
BA9XX-50-B
3-way flanged ball valve; Flange DN50; PN16; Body Zinc plated steel; Ball stainless steel 1.4571; Seals PEEK/Special; Medium temperature -10...+250°C; Pressure range 0-16bar; L-bore; ISO flange F05; SW17; 80Nm
BA826-12N-L-A-01
Ball valve made of stainless steel; With spring return; ATEX II 2 G/D; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE/MFQ; Medium temperature -40...+180°C; Connection 1/2"NPT; Nominal diameter 15mm; Pressure range 0...64bar; Length 67mm
C3M-BA112-150
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA112-150-L
Flanged ball valve Series BA112-L; Flange ANSI300; Flange thread Metrical; Full bore; Body, Ball 1.4401; Seals PTFE glass fibre reinforced/FKM; Pressure range 0...50bar; Medium temperature -20...+160°C; Nominal diameter 150mm; Length 232mm
BA112-150-L-3C
Flanged ball valve Series BA112-L-3C; Flange ANSI300; Flange thread Metrical; Full bore; Body, Ball 1.4401; Seals PTFE glass fibre reinforced/FKM; Pressure range 0...50bar; Medium temperature -20...+160°C; Nominal diameter 150mm; Length 232mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA050-80-L-A-01
Flanged ball valve Series BA050-L-A-01; For steam; ATEX II 2 G/D; Fire-safe; TA-Luft; Flange PN16; V-Ball 30-60°; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Pressure range Steam 0...15bar; Medium temperature -20...+198°C; Nominal diameter 80mm; Length 122mm
BA527-12-B
High pressure ball valve; Female thread; Zinc plated steel; Ball stainless steel; Seals PEEK/NBR; Medium temperature -20...+60°C; G1/2"; Nominal diameter 13mm; Pressure range 0-350bar; Mounting flange; F03/SW9
BA860-12-B
High pressure ball valve Series BA860; Female thread; Drilled for mounting an actuator; Body, Ball 1.4571/1.4404; Seals PEEK/NBR With erosion protection ring; For gases; Medium temperature -30...+100°C; G 1/2"; Nominal diameter 13mm; Pressure range 0...500bar; Length 83mm; Flange ISO5211 F03; Square 9mm
BA234-34-L-02
High pressure ball valve; Female thread; Body, Ball 1.4571/1.4404; Seals POM/NBR; Medium temperature -30...+100°C; For liquids; G 3/4"; Nominal diameter 20mm; Pressure range 0...350bar; Length 95mm; Incl. mounting holes
