Ball valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BA869-12-L-01
Stainless steel ball valve; full passage; two-part; Internal thread; Housing, Ball 1.4401; Seals PTFE-graphitverstärkt/MFQ; Medium temperature -50...+160°C; Connection RP 1/2"; Nominal diameter 15mm; Print area 0-140bar; Installation length 66mm; Compensation hole on the input side; with control ball V 60°
BA415-12-B
High-pressure ball valve Series BA415; Internal thread; Housing, Ball 1.4571; Seals POM/EPDM; Medium temperature -30...+100°C; for liquids; G 1/2"; Nominal diameter 13mm; Print area 0...500bar; Installation length 83mm; Free shaft end F03/Square 9mm
C3M-BA409-38N-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-38-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-12N-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-112N-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-34N-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-112-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-114-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA409-114N-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
BA245-25-L-A
flanged ball valve series BA245; ATEX II 2 G/D; fire-safe; TA-Luft; length according to EN558−1R101; flange ANSI 600; full bore; body and ball AISI 316; seals PTFE-metal reinforced/FKM; pressure range 0...100bar; medium temperature -20...+160°C; nominal diameter 25mm; length 65mm
BA469-12-L-AH
ball valve made of stainless steel series BA469-L-AH; full bore; two-parts type; female thread; body, ball AISI 316L; seals PTFE reinforced with carbographite; medium temperature -20...+160°C; connection RP 1/2"; nominal diameter 15mm; Class 800; pressure range 0-138bar; length 75mm; antistatic design; Fire-Safe; ATEX II 2 G/D c T3; free of oil and grease for hydrogen
BA469-38-L-AH
ball valve made of stainless steel series BA469-L-AH; full bore; two-parts type; female thread; body, ball AISI 316L; seals PTFE reinforced with carbographite; medium temperature -20...+160°C; connection RP 3/8"; nominal diameter 10mm; Class 800; pressure range 0-138bar; length 67mm; antistatic design; Fire-Safe; ATEX II 2 G/D c T3; free of oil and grease for hydrogen
BA851-112-L
Ball valve made of stainless steel; Full bore; Three-parts type; Female thread; Body, Ball 1.4401; Stem 1.4542; Seals PEEK/FFKM; Medium temperature -20...+250°C; RP 11/2"; Nominal diameter 40mm; Pressure range 0-25bar; Length 116mm
BA036-10-L-03
ball valve made of stainless steel; full bore; three-parts type; female thread; body, ball AISI 316; seals PTFE-reinforced/FKM-perox; pressure range 0…15bar; medium temperature -20...+200°C; RP 1"; nominal diameter 15mm; length 92mm; V-ball 30-60°
BA036-10-L-04
ball valve made of stainless steel; full bore; three-parts type; female thread; body, ball AISI 316; seals PTFE-reinforced/FKM-perox; pressure range 0…15bar; medium temperature -20...+200°C; RP 1"; nominal diameter 15mm; length 92mm; V-ball 90°
BA872-100-L
flanged ball valve series BA872; flange ANSI150; flange thread metrical; full bore; body steel; ball AISI 304; seals PTFE-graphite reinforced/FKM; pressure range 0...15bar; medium temperature -20...+198°C; nominal diameter 100mm; length 152mm
BA841-10-B-AH
ball valve made of stainless steel series BA841; ATEX II 2G Ex h IIC T6...T1 Gb / II 2D Ex h IIIC T85°C...T450°C Db; Fire-Safe; Class 800; full bore; two-parts type; female thread; body, ball AISI 316L; seals PEEK/HNBR/V-Pack PTFE; medium temperature -40...+180°C; nominal diameter 25mm; pressure range 0...138bar; connection RP 1"; length 105mm; mounting flange ISO5211 F05; free of oil and grease for hydrogen
BA889-18-L
Ball valve with venting Series BA553; Brass; Mini type; Female thread/Female thread; Seals PTFE/NBR; Medium temperature -20...+80°C; Pressure range -0.99...20bar; G 1/8"; Nominal diameter 6mm; Length 35mm
C3M-BA048-50
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
