Ball valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BA477-25-B-AH3N-01
high pressure ball valve drilled for mounting an actuator series BA477-B-AH3N; butt weld ends; body AISI 316Ti; ball and stem Nitronic-50; seals PEEK/FKM(AED)/PTFE; medium temperature -40...+85°C; connection 33,7 x 8,8mm; nominal diameter 25mm; pressure range 0...650bar; flange ISO5211 F05; square 12mm; free of oil and grease for hydrogen; incl. 3.1-inspection document according to DIN EN 12266-1 P12 high pressure gas test; incl. inspection certificate EN-10204-3.1; for housing material and internal parts; incl. ATEX-certificate
C3P-BA477-25-AH-01
inspection certificate EN-10204-3.1; for housing, screw connection, control shaft, ball, screw connection control shaft and pressure nut
CHA-BA477-25-AH-01
inspection document according to DIN EN 12266-1 P12 high pressure gas test
BA816-65-B-AH
Ball valve made of stainless steel; ATEX II 2 G/D T4; Full bore; Body And Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+170°C; Connection Butt weld ends According to ISO 1127; Nominal diameter 65mm; Pressure range 0…40bar; Length 154mm; Flange ISO5211 F10; Square 22mm; Free of oil and grease for hydrogen
BA816-65-S0-AH
ball valve with pneumatic actuator; ATEX II 2 G/D T4; butt weld ends according to ISO 1127; body, ball AISI 316L; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+170°C; nominal diameter 65mm; pressure range 0-40bar; length 154mm; actuator PAS1155; free of oil and grease for hydrogen
BA539-18-L
ball valve made of brass; mini type; with drain hole; female thread; seals PTFE/NBR; medium temperature -15...+80°C; turning handle polyamide; pressure range 0…20bar; G 1/8"; nominal diameter 5,5mm; length 36mm
BA086-125-L-A
flanged ball valve ATEX II 2 G/D; fire-safe; TA-Luft; flange PN16, full bore; body and ball AISI 316; seals PTFE-graphite/FKM; pressure range 0...16bar; medium temperature -20...+160°C; nominal diameter 125mm; length 196mm
BA415-38-L
high pressure ball valve; female thread; body, ball AISI 316Ti/AISI 316L; seals POM/EPDM; medium temperature -30...+100°C; for liquids; G 3/8"; nominal diameter 10mm; pressure range 0...500bar; length 72mm
BL-BA358-25-L
ball suitable to ball valve BA358, series 72; DN25; material stainless steel AISI 304
BL-BA358-50-L
ball suitable to ball valve BA358, series 72; DN50; material stainless steel AISI 304
BL-BA358-80-L
ball suitable to ball valve BA358, series 72; DN80; material stainless steel AISI 304
HL-BA358-25/32-L
hand lever suitable to ball valve BA358; DN25-DN32; material steel
HL-BA358-40/50-L
hand lever suitable to ball valve BA358; DN40-DN50; material steel
HL-BA358-65/80-L
hand lever suitable to ball valve BA358; DN65-DN80; material steel
CP-BA078-65
connection part for ball valve BA078-65
BA848-50-L-AH
ball valve made of stainless steel; ATEX II 2 G/D T4; full bore; body AISI 316L polished; ball AISI 316L; seals MPTFE/FKM; medium temperature -20...+170°C; welding ends according to ASTM A-270 50,8 x 1,65; nominal diameter 50mm; pressure range 0…40bar; length 136mm; free of oil and grease for hydrogen
BA866-25-L-A03G
high pressure ball valve series BA866-L-A03G; flange PN400; body AISI 316Ti; ball AISI 316Ti hard chrome plated; seals PEEK(ATEX)/FKM(AED); with erosion protection ring; for gases; medium temperature -40...+200°C; nominal diameter 25mm; pressure range 0...400bar; length 230mm; free of oil and grease; incl. 3.1-inspection document according to DIN EN 12266-1; incl. inspection certificate EN-10204-3.1; for body material; incl. ATEX-certificate
BA864-12-L
ball valve made of brass series BA864; for insulated pipework; full bore; female thread; seal PTFE; medium temperature -20...+160°C; hand lever aluminum; connection Rp 1/2"; nominal diameter 15mm; pressure range 0-50bar; length 59mm
C3K-BA866-25-A0
3.1-Inspection document According to DIN EN 12266-1 P10/P11/P12; For pressure, function and tightness
BA358-150-L-A
Flanged ball valve Series BA358-L-A; ATEX II 2 G/D; Flange ANSI150; Flange thread UNC; full passage; Housing Steel; Ball 1.4301; Seals PTFE-glass fibre reinforced/FKM; Print area 0…20bar; Medium temperature -20...+160°C; Nominal diameter 150mm; Installation length 232mm;
