Ball valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BA151-20-L
Flanged ball valve; ATEX II 2G/D c T3; TA-Luft; DVGW-gas-approved; Length According to EN558−1R27; Body Steel; Ball 1.4301; Seals Fibre-glass-reinforced PTFE/HNBR; Flange PN40; Full bore; Medium temperature 0...+50°C; Pressure range 0...40bar; Nominal diameter 20mm; Length 120mm
BA749-15-L-A
flanged ball valve; ATEX II 2 G/D; fire-safe; TA-Luft; flange ANSI 300; length according to ANSI B16.10; housing steel LCB; ball AISI 304; seals fibre-glass-reinforced PTFE/V-pack; medium temperature -40...+160°C; pressure range 0...50bar; nominal diameter 15mm; length 140mm
SK-BA055-80-B
Seal kit for Ball valve BA055-80-B
BA045-40-L-A
Flanged ball valve; Fire-Safe/Antistatik According to ATEX/TA-Luft; Flange PN40, Full bore; Body Steel; Ball 1.4301; Seals PTFE-reinforced/FKM; Pressure range 0...40bar; Medium temperature -10...+160°C; Nominal diameter 40mm; Length 63,5mm
BA597-15-L-A-01
Ball valve made of stainless steel; Atex II 2G Ex h IIC T4 Gb II 2D Ex h IIIC T135°C Db; ATEX zone 1 and 21; ; Full bore; Body, Ball 1.4404; Seals PTFE/FFKM; Medium temperature -20...+160°C; Welding ends ISO 1127 17,2 x 1,65; Nominal diameter 15mm; Pressure range 0…64bar; Length 95mm; With hand lever
BA650-10-B
Ball valve PVC; 3-way-type; Full bore; Female thread; Seals PTFE/FPM; Connection 1"; Nominal diameter 25mm; Pressure range 0-16bar; For mounting an actuator F04, SW11; Threaded sleeves Supplied seperately; Ball L
BA081-12N-L-A-01
Ball valve made of stainless steel; With spring return; ATEX II 2 G/D; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Connection 1/2"NPT; Nominal diameter 15mm; Pressure range 0...64bar; Length 67mm
700000-2"
Ball valve made of stainless steel; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Connection RP 2"; Nominal diameter 50mm; Pressure range 0-64bar; Length 131mm
BA069-20-L-P1
Ball valve made of stainless steel; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0…64bar; Length 131mm; Incl. Technical valve passport RU According to TR CU 032/2013; Incl. TR CU 032/2013 (Incl. Strength calculation), TR CU 010/2011; Incl. EAC-Certificate
BA761031-20
Flanged ball valve; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1 R27; Full bore; Body Zinc plated steel; Ball 1.4301; Seals PTFE/Graphoil/FKM; Medium temperature -10...+160°C; Nominal diameter 20mm; Pressure range 0...40bar; Flange PN40; Length 120mm
BA267-112-L
Ball valve made of stainless steel; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals fibre-glass-reinforced PTFE/FKM; Medium temperature -20...+160°C; Connection RP 11/2"; Nominal diameter 40mm; Pressure range 0-64bar; Length 110mm
BA501-34
Ball valve made of stainless steel; DVGW-gas-approved; For mounting an actuator; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE; Medium temperature -20...+60°C; Connection RP 3/4"; Nominal diameter 20mm; Pressure range 0-4bar; Length 70mm
BA720711-20
Flanged ball valve; Flange PN16, Full bore; Body, Ball 1.4401; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Nominal diameter 20mm; Length 40mm
720009-50
Flanged ball valve Series 720009; Flange ANSI150; Flange thread Metrical; Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...20bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Length 82mm
BA492-16S-L
High pressure ball valve; Male thread according to ISO 8434-1 (DIN 2353); Body Steel, Ball Hard chrome plated steel; Seals POM/NBR; ; Medium temperature -20...+100°C; Connection 16S/M24x1,5; Nominal diameter 13mm; Pressure range 0-800bar; Length 114mm
BA761-25-L-AH
ball valve made of stainless steel; ATEX II 2 G/D T4; full bore; housing and ball AISI 316; seals PTFE/FKM; medium temperature -20...+170°C; connection butt weld ends according to ISO 11850; nominal diameter 25mm; pressure range 0…64bar; length 106mm; free of oil and grease for hydrogen
BA670-12N-L
High pressure ball valve; Female thread; Body 1.4571; Ball 1.4571 Hard chrome plated; Seals POM/NBR; Medium temperature -30...+100°C; With erosion protection ring; 1/2"NPT; Nominal diameter 13mm; Pressure range 0...500bar; Length 83mm
BA705-12-L-03
Ball valve made of stainless steel; Female thread; Body And Ball 1.4571; Seals Fibre-glass-reinforced PTFE/FFKM/FEP; Temperature range -30…+150°C; Connection 1/2"; Nominal diameter 15mm; Pressure range 0..63bar; Length 75mm; Incl. 2 Mounting holes
BA384-20-LLD-A
Flanged ball valve Series BA384-LLD-A; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Full bore; Body Steel A352-LCB, Ball 1.4301; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Medium temperature -40...+180°C; With locking device; Nominal diameter 20mm; Pressure range 0...40bar; Flange PN40; Length 120mm
BA384-20-LLD-A3C
Flanged ball valve Series BA384-LLD-A3C; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Full bore; Body Steel A352-LCB, Ball 1.4301; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Medium temperature -40...+180°C; With locking device; Nominal diameter 20mm; Pressure range 0...40bar; Flange PN40; Length 120mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
