Ball valves - manually operated

Ball valve made of stainless steel; Full bore; Three-parts type; Socket weld ends; Body, Ball 1.4401; Seals PTFE-Graphite reinforced/EPDM; Medium temperature -40...+160°C; Nominal diameter 20mm; Pressure range 0-40bar; Length 76mm

720009-20

Flanged ball valve Series 720009; Flange ANSI150; Flange thread Metrical; Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...20bar; Medium temperature -20...+160°C; Nominal diameter 20mm; Length 40mm

BA034-20-L-3C-01

Ball valve made of stainless steel; Full bore; Three-parts type; Butt weld ends; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+160°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Nominal diameter 20mm; Pressure range 0...40bar; Length 76mm; Incl. Stem extension 55mm

SYS-602-03

Test report EN10204-2.2 For material, Inspection certificate EN-10204-3.1; For Pressure

BA485-12-L-A

Ball valve made of stainless steel; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Body Polished; Seals PTFE/EPDM; Medium temperature -20...+170°C; Connection G 1/2"; Nominal diameter 15mm; Pressure range 0...100bar; Length 62mm; ATEX II 2 G/D T4

BA469-14-L-A3C

Ball valve made of stainless steel; ATEX II 2G Ex h IIC T6...T1 Gb / II 2D Ex h IIIC T85°C...T450°C Db; Fire-Safe; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Connection RP 1/4"; Nominal diameter 8mm; Class 800; Pressure range 0...138bar; Length 67mm; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA469-14N-L-A3C

Ball valve made of stainless steel Series BA469-L-A3C; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Connection 1/4"NPT; Nominal diameter 8mm; Class 800; Pressure range 0-138bar; Length 67mm; Antistatic design; Fire-Safe; ATEX II 2 G/D c T3; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA469-38-L-A3C

Ball valve made of stainless steel Series BA469-L-A3C; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Connection RP 3/8"; Nominal diameter 10mm; Class 800; Pressure range 0-138bar; Length 67mm; Antistatic design; Fire-Safe; ATEX II 2 G/D c T3; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA469-38N-L-A3C

Ball valve made of stainless steel Series BA469-L-A3C; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Connection 3/8"NPT; Nominal diameter 10mm; Class 800; Pressure range 0-138bar; Length 67mm; Antistatic design; Fire-Safe; ATEX II 2 G/D c T3; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA410-12-L-A

ball valve made of stainless steel; ATEX II 2 G/D; full bore; three-parts type; female thread; housing, ball AISI 316; seals PTFE-reinforced with carbographite/EPDM; medium temperature -40...+160°C; with additional compensation hole in the ball; RP 1/2"; nominal diameter 15mm; pressure range 0...64bar; length 65mm

BA663-10-L

High pressure ball valve; Female thread; Body Zinc plated steel; Ball Hard chrome plated steel; Seals POM/NBR; Medium temperature -10...+90°C; G 1"; Nominal diameter 25mm; Pressure range 0...320bar; Length 90mm

9010-2"

Ball valve, aluminium hand lever, thread i/i body nickel-plated brass, seal PTFE, CZ gas approval

BA033-10-L-3C

ball valve made of stainless steel; full bore; three-parts type; female thread; housing, ball AISI 316; seals PTFE/FKM; medium temperature -20...+160°C; incl. inspection certificate EN-10204-3.1; for material, pressure, function and tightness; RP 1"; nominal diameter 25mm; pressure range 0...40bar; length 92mm

BA452-F050-L

Ball valve PVC; Full bore; Fusion socket 63mm; Seals PTFE/EPDM; Medium temperature 0...+60°C; Hand lever; Nominal diameter 50mm; Pressure range 0...16bar

BA168-12N-L-A

Ball valve made of stainless steel; ATEX II 2 G/D T4; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Body Polished; Seals PTFE/FKM; Medium temperature -20...+160°C; NPT 1/2"; Nominal diameter 15mm; Pressure range 0...100bar; Length 62mm

BA469-10N-L-A3C

Ball valve made of stainless steel Series BA469-L-A3C; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Connection 1"NPT; Nominal diameter 25mm; Class 800; Pressure range 0-138bar; Length 105mm; Antistatic design; Fire-Safe; ATEX II 2 G/D c T3; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness

BA761030-15

Flanged ball valve; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1 R27; Full bore; Body, Ball 1.4408; Seals PTFE/Graphoil/FKM; Medium temperature -20...+160°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Nominal diameter 15mm; Pressure range 0...40bar; Flange PN40; Length 115mm

BA452-S080-L

Ball valve PVC; Full bore; Solvent cement socket 90mm; Seals PTFE/EPDM; Medium temperature 0...+60°C; Hand lever;Nominal diameter 80mm; Pressure range 0...16bar
