Ball valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BA599-32-B
ball valve made of stainless steel; full bore; body, ball AISI 316L; seals PTFE/FKM; medium temperature -20...+160°C; welding ends DIN11850 35x1,5; nominal diameter 32mm; pressure range 0…25bar; length 126mm; with bare shaft; flange ISO 5211; F05; SW14
BA470-25-L
flanged ball valve; 3-way-type; sealing on three ports; full bore; body, ball AISI 316; seals PTFE / metal reinforced/FKM; medium temperature -20...+200°C; nominal diameter 25mm; length 150mm; pressure range 0…40bar; flange PN40; ball T
C3M-BA051-25-A0
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
BA599-50-B-3E
Ball valve made of stainless steel; Full bore; Body, Ball 1.4404; Seals PTFE/FKM; Medium temperature -20...+160°C; Welding ends DIN11850 53x1,5; Nominal diameter 50mm; Pressure range 0…25bar; Length 165mm; With bare shaft; Flange ISO 5211; F05; SW14; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; FDA-Approval
BA594-50-L-3E
Ball valve made of stainless steel; Full bore; Three-parts type; Body, Ball 1.4404; Seals PTFE/FKM; Medium temperature -20...+160°C; Welding ends DIN11850 53x1,5; Nominal diameter 50mm; Pressure range 0…25bar; Length 165mm; With hand lever; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; FDA-Approval
BA222-TCA20-D0-3E
Ball valve with pneumatic rotary actuator; 3-way version; sealing on four ports; full bore; body, ball AISI 316L; seals PTFE/FKM; medium temperature -20...+170°C; Tri-Clamp connection 2" DIN 32676 TAB.2 REIHE A;nominal diameter 50mm; pressure range 0-40bar; ball L; length 182mm; incl. inspection certificate EN-10204-3.1; for material, pressure, function and tightness; FDA-approval; PAD075
BA599-65-B-3E
ball valve made of stainless steel; full bore; body, ball AISI 316L; seals PTFE/FKM; medium temperature -20...+160°C; welding ends DIN11850 70x2; nominal diameter 65mm; pressure range 0…25bar; length 191mm; with bare shaft; flange ISO 5211; F07; SW17; incl. inspection certificate EN-10204-3.1; for material, pressure, function and tightness; FDA-approval
C3K-BA686-12-AH-01
3.1-inspection document according to DIN EN 12266-1 P10/P11/P12; for pressure, function and tightness
CP-BA078-15
connection part for ball valve BA078-15
FR-BA261-20-L-AH
fixing ring for the spindle nut of ball valve BA261-20-L-AH
FR-BA261-25/32-L-AH
fixing ring for the spindle nut of ball valve BA261-25/32-L-AH
FR-BA261-40/50-L-AH
fixing ring for the spindle nut of ball valve BA261-40/50-L-AH
FR-BA162-15/20-L-AH
fixing ring for the spindle nut of ball valve BA162-15/20-L-AH
FR-BA162-25/32-L-AH
fixing ring for the spindle nut of ball valve BA162-25/32-L-AH
FR-BA162-40/50-L-AH
fixing ring for the spindle nut of ball valve BA162-40/50-L-AH
FR-BA049-20-L-A
fixing ring for the spindle nut of ball valve BA049-20-L-A
BA148-80-CG
Flanged ball valve with electric actuator; fire-safe; TA-Luft; length according to EN558−1 R27; full bore; body zinc plated steel; ball AISI 304; seals: PTFE-reinforced/FKM; medium temperature -10...+160°C; nominal diameter 80mm; pressure range 0-16bar; flange PN16; length 180mm; operating time 32-320s; voltage 24VDC
C3K-BA110-25-T0-A
Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
C3M-BA110-25-LLD-A
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
C3M-BA126-25
inspection certificate EN-10204-3.1; for material, pressure, function and tightness
