Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA049-150-H8-01
Flanged ball valve With Hydraulic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 150mm; Length 232mm; Double acting actuator; HAD63-03; Mounted limit switch box IP67, 2 inductive EExi proximity switches; Control pressure 10...120bar;
BA049-32-S0-A3C
Flanged ball valve with pneumatic actuator; Flange PN16; ATEX According to Directive 2014/34/UE; Antistatic; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855; ATEX II 2G/D c T6; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA049-40-S0-A3C
Flanged ball valve with pneumatic actuator; Flange PN16; ATEX According to Directive 2014/34/UE; Antistatic; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 40mm; Length 63,5mm; Actuator PAS0855; ATEX II 2G/D c T6; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA049-50H6-01
Flanged ball valve With Hydraulic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Double acting actuator; HAD50-01; Mounted limit switch box IP67, 2 inductive EExi proximity switches; Control pressure 10...20bar;
BA049-50-H6-02
Flanged ball valve With Hydraulic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Double acting actuator; HAD50-01; Mounted limit switch box IP67, 2 inductive EExi proximity switches; Control pressure 10...20bar;
BA049-80-CE-01
Flanged ball valve with electrical actuator Incl. Positioner; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; DN 80mm; Pressure range 0-16bar; Length 122mm; 2 potential-free contacts for end position feedback; Operating time 36-73s; Voltage 24VDC. Electrical actuator PSQ103AMS; In- and output signal 0(4)-20mA bzw. 0(2)-10V; Fault relay
BA049-80-S0-01
Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+198°C; DN 80mm; Pressure range 0-16bar; Length 122mm; Actuator PAS1605-H
BA049-80-S0-02
Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+198°C; DN 80mm; Pressure range 0-16bar; Length 122mm; Actuator PAS1605-H; Mounted limit switch box
BA050-150-D2-A-01
Ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; For steam; Flange PN16; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Double acting actuator; Control pressure 4...8bar; Medium temperature -20...+198°C; Pressure range Steam 0...15bar; Nominal diameter 150mm; Length 232mm; Actuator PAD160-PS; Actuator PTFE-coated; Pinion made of stainless steel
BA051-100-S0-A-01
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; TA-Luft; Length According to EN558−1 R27; Length According to EN558−1 R27; Body, Ball 1.4408; Seals PTFE/HNBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+150°C; Nominal diameter 100mm; Pressure range 0...16bar; Flange PN16; Length 190mm; Actuator PAS1255-L; Seals Silicone
BA051-125-CE-01
Flanged ball valve with electrical actuator; Length According to EN558−1R27; Body, Ball 1.4408; Seals PTFE/Graphoil/FKM; Medium temperature -20...+160°C; DN 125mm; Pressure range 0-16bar; Flange PN16; Length 325mm; 2 potential-free contacts for end position feedback; Operating time 60s; Voltage 24VAC/DC. Electrical actuator PSQ203AMS; In- and output signal 0(4)-20mA bzw. 0(2)-10V; Fault relay
BA051-125-H8-01
Flanged ball valve With Hydraulic actuator; Fire-Safe/Antistatik According to ATEX/TA-Luft; Length According to EN558−1 R27; Full bore; Body 1.4408; Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 125mm; Pressure range 0-16bar; Flange PN16; Length 325mm; Double acting actuator; HAD40-02; Mounted limit switch box BE45 220M33; IP67, Control pressure 10...120bar;
BA051-150-H8-01
Flanged ball valve With Hydraulic actuator; Fire-Safe/Antistatik According to ATEX/TA-Luft; Length According to EN558−1 R27; Full bore; Body 1.4408; Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 150mm; Pressure range 0-16bar; Flange PN16; Length 350mm; Double acting actuator; HAD50-02; Mounted limit switch box BE45 220M33; IP67, Control pressure 10...120bar;
BA051-200-H8-01
Flanged ball valve With Hydraulic actuator; Fire-Safe/Antistatik According to ATEX/TA-Luft; Length According to EN558−1 R27; Full bore; Body 1.4408; Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 200mm; Pressure range 0-16bar; Flange PN16; Length 400mm; Double acting actuator; HAD63-04; Mounted limit switch box IP67, 2 inductive EExi proximity switches; Control pressure 10...120bar;
BA051-20-QH
Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body, Ball 1.4408; Stem seal 2-fold PTFE/FKM-Packing; Medium temperature -20...+160°C; DN 20mm; Pressure range 0-40bar; Flange PN40; Length 120mm; Operating time 8s; Voltage 100-240VAC; Accumulator for safety position NO
BA051-25-QH
Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body, Ball 1.4408; Stem seal 2-fold PTFE/FKM-Packing; Medium temperature -20...+160°C; DN 25mm; Pressure range 0-40bar; Flange PN40; Length 125mm; Operating time 8s; Voltage 100-240VAC; Accumulator for safety position NO
BA051-50-CL
Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body, Ball 1.4408; Seals PTFE/Graphoil/FKM; Medium temperature -20...+160°C; DN 50mm; Pressure range 0-40bar; Flange PN40; Length 150mm; Operating time 9s; Voltage 24VAC/DC; Incl. Positioner 4-20mA/0-10V; For a maximum of 100 operations a day
BA051-80-0N-A
flanged ball valve with electrical actuator; protection class IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; length according to EN558−1 R27; housing, ball AISI 316; seals PTFE/FKM; medium temperature -20...+160°C; DN 80mm; pressure range 0-16bar; flange PN16; length 180mm; operating time 30s; voltage 15-30V/50-60Hz; 12-48VDC
BA051-80-S0-A-01
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; TA-Luft; Length According to EN558−1 R27; Length According to EN558−1 R27; Body, Ball 1.4408; Seals PTFE/HNBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+150°C; Nominal diameter 80mm; Pressure range 0...16bar; Flange PN16; Length 180mm; Actuator PAS1255-L; Seals Silicone
BA052-100-H6-02
Flanged ball valve With Hydraulic actuator; Flange PN40; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+160°C; Pressure range 0...40bar; Nominal diameter 100mm; Length 152mm; Double acting actuator; HAD80-01; Mounted limit switch box IP67, 2 inductive EExi proximity switches; Control pressure 13...20bar;
