Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA040-080-T0
Flanged ball valve with pneumatic actuator; Flange PN16; Body Cast iron EN-GJL-250; Ball 1.4301; Seals PTFE/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+120°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 180mm; Length EN558-1 R14; Actuator PAS1255; Safety position NO
BA047-50-0L
Ball valve with electrical actuator; 3-way-type; Sealing on two sides; Pressure inlet just in front; Reduced bore; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -10...+160°C; Nominal diameter 50mm; DN ball 40mm; Length 82mm; Operating time 9s; Voltage 24VAC/DC; Ball T
BA196-40-S0
Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Without dead space; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 40mm; Length 63,5mm; Actuator PAS1255
BA036-30-D0-01
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Double acting actuator; Control pressure 5,5...8bar; For steam Medium temperature -20...+198°C; RP 3"; Nominal diameter 80mm; Pressure range 0-15bar; Length 180mm; Actuator PAD085-H High temperature design
BA178-25-S0-A-01
Flanged ball valve with pneumatic actuator; Fire-Safe/Antistatik According to ATEX/TA−Luft; Length According to ANSI B16.10; Flange ANSI150; Body 1.4408; Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...20bar; Nominal diameter 25mm; Length 127mm; Actuator PAS0635-SS, Stainless steel construction
BA049-50-D0-01
STASTO Combination#br#Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator PAD075; Limit switch box EB0X03; 5/2-way solenoid valve - NAMUR type ABS54; 24VDC-LED
BAC1-010-SSCV-S0
Ball valve, carbon-graphite-PTFE seal.125 single-acting, body and ball 1.4401, female/female thread connection RP1/2"
BA078-65-0L
Ball valve with electrical actuator; Butt weld ends; Body Steel; Ball 1.4301; Seals PTFE-reinforced/FKM; Compensation hole; Medium temperature -10...+160°C (Steam -10...+198°C); Nominal diameter 65mm; Pressure range 0…16bar; Pressure range Steam 0...15bar; Length 153mm; Operating time 27s; Voltage 24VAC/DC
BA080-212-PH
Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM/EPDM; Medium temperature 0...+100°C; RP 21/2"; DN 65mm; Pressure range 0-25bar; Length 165mm; Operating time 9s; Voltage 100…240VAC; NC-Accumulator for safety position
BADA-080-IITV-D0
Ball valve with pneumatic rotary actuator 100 double-acting, body and ball 1.4301, flange PN 16 connection DN80
BA791-80-B-AH
Ball valve made of stainless steel; ATEX II 2 G/D T4; Bare shaft; Butt weld ends; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/EPDM; Medium temperature -20...+170°C; Connection 88,9 x 2mm; Nominal diameter 80mm; Pressure range 0…40bar; Length 184mm; Flange ISO5211 F10; Square 22mm; Free of oil and grease for hydrogen
BA066-34-0L
Ball valve with electrical actuator; Female thread; Body, Ball 1.4571; Seals PEEK/FKM; For liquids; Medium temperature -20...+100°C; G 3/4"; Nominal diameter 20mm; Pressure range 0-400bar; Length 96mm; Operating time 9s; Voltage 24VAC/DC
BA116-50-T0-A
Flanged ball valve with pneumatic actuator; NO; Flange PN63; Body steel A350-LF2; Ball 1.4301; Seals Fibre-glass-reinforced PTFE/PTFE/Graphoil/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0…63bar; Nominal diameter 50mm; Length 100mm; Actuator PAS1155; ATEX zone 1 and 21
BA116-50-T0-A3C
Flanged ball valve with pneumatic actuator; NO; Flange PN63; Body steel A350-LF2; Ball 1.4301; Seals Fibre-glass-reinforced PTFE/PTFE/Graphoil/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Pressure range 0…63bar; Nominal diameter 50mm; Length 100mm; Actuator PAS1155-B; ATEX zone 1 and 21
BA162-25-0H
Flanged ball valve with electrical actuator; Fire-safe; TA-Luft; Length According to EN558−1R101; Flange PN100; Full bore; Body Stainless steel AISI 316, Ball 1.4404; Seals PTFE/FKM/Graphite; Pressure range 0...100bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Pressure range 0...100bar; Length 65mm; Operating time 27s; Voltage 100-240VAC
VRX75-0Q20-Q17-01
Electrical actuator; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 75Nm; Operating time 20sec; Flange ISO5211 F05/F07-star 17mm; Voltage 100-240V/50-60Hz; 100-350VDC; Protection class IP68; Incl. Potentiometer 1000 Ohm; ATEX II 2GD, Ex dIIB T6 Gb, Ex tbIIIC T80°C C Db
BA044-80-0L-01
Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body Zinc plated steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; DN 80mm; Pressure range 0-16bar; Flange PN16; Length 180mm; Operating time 27s; Voltage 24VAC/DC, Actuator VB190 (190Nm) Instead of VB110
BA162-25-S0-AH-01
ball valve with pneumatic actuator; ATEX II 2G/D c T3; fire-safe; TA-Luft; length according to EN558−1R101; flange PN100, groove and tongue according to DIN EN 1092-1; full bore; housing stainless steel AISI 316, ball AISI 316L; seals PTFE/FKM/graphite; pressure range 0...100bar; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 25mm; pressure range 0...100bar; length 65mm; actuator PAS0855; free of oil and grease for hydrogen
BA045-65-0L
Flanged ball valve with electrical actuator; Flange PN40; Body Steel; Ball 1.4301; Seals Fibre-glass-reinforced PTFE/FKM; Medium temperature -10...+160°C; DN 65mm; Pressure range 0…40bar; Length 103mm; Operating time 27s; Voltage 24VAC/DC
BA389-50-S0-A
Flanged ball valve with pneumatic actuator Series BA389-S0-A; ATEX II 2 G/D; Fire-safe; TA-Luft; Full bore; Flange PN16/40; Body, Ball 1.4401; Seals TFM-MPTFE/PTFE/Graphoil; Stem sealing V-Pack; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0…40bar; Nominal diameter 50mm; Length 83mm; Actuator PAS1155
