Ball valves - automatically operated

BAEA-065-UITV-D0A

Ball valve with pneumatic rotary actuator 85 double-acting, body 1.0619, ball 1.4408, flange PN 16 ATEX anti-static connection DN65

Ball valve with pneumatic actuator; Flange PN40; Body, Ball 1.4401; Seals PTFE/Kalrez, Double acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+160°C; Pressure range 0...40bar; Nominal diameter 40mm; Length 140mm; Actuator PAD063; Incl. Mounting bridge Height 60mm

VS100-0E15-Q22

Electrical actuator; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 100Nm; Operating time 15sec; Flange ISO5211 F07/F10-star 22mm; Voltage 24V AC/DC; Protection class IP67; CSA-Certified

BA045-80-0H

Flanged ball valve with electrical actuator; Flange PN40; Body Steel; Ball 1.4301; Seals Fibre-glass-reinforced PTFE/FKM; Medium temperature -10...+160°C; DN 80mm; Pressure range 0…40bar; Length 122mm; Operating time 50s; Voltage 100-240V50-60Hz

VB190M-0E27-Q17

Electrical actuator; Metal; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 190Nm; Operating time 27s; Flange ISO5211 F07/F10-star 17mm; Voltage 24VAC/DC; Protection class IP68

BA730-10-S0-A

ball valve with pneumatic actuator; 3-way-type; ATEX zone 1 and 21 II 2 G-D T4; sealing on three ports; housing AISI 316L polished; ball AISI 316L; seals PTFE/Kalrez; single acting actuator; full bore; control pressure 5,5...8bar; medium temperature -40...+160°C; G 1"; nominal diameter 25mm; pressure range 0…64bar; length 102mm; actuator PAS1005; ball T

BA752-50-S0

ball valve with pneumatic actuator; flange PN16; housing, ball AISI 316; seals PTFE/EPDM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 50mm; length 82mm; actuator PAS1005; with additional compensation hole in the ball

BA050-50-S2

Ball valve with pneumatic actuator; For steam; Flange PN16; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -20...+198°C; Pressure range Steam 0...15bar; Nominal diameter 50mm; Length 82mm; Actuator PAS1153

BA043-50-PH

Flanged ball valve with electrical actuator; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; DN 50mm; Pressure range 0-16bar; Length 82mm; Operating time 9s; Voltage 100-240VAC; NC-Accumulator for safety position

BA162-20-S0-A-01

ball valve with pneumatic actuator; ATEX II 2G/D c T3; fire-safe; TA-Luft; length according to EN558−1R101; flange PN100; full bore; body stainless steel AISI 316, ball AISI 316L; seals PTFE/FKM/graphite; pressure range 0...100bar; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 20mm; pressure range 0...100bar; length 60mm; actuator PAS0755; Oil and grease-free design for hydrogen and oxygen; ATEX II 2G Ex h IIC T6...T1 Gb and II 2D Ex h IIIC T85°C...T450°C Db

BA137-50-S0-01

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Antistatic design; ATEX; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator PAS1155

BA033-20-PH

Ball valve with electrical actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; RP 2"; DN 50mm; Pressure range 0-25bar; Length 136mm; Operating time 9s; Voltage 100-240VAC; NC-Accumulator for safety position

8E009004-80

Motorised ball valve, 100-240VAC, DN80/PN16 body GG25, ball brass, seal PTFE/NBR

BA052-50-S0-A

Flanged ball valve with pneumatic actuator; ATEX II 2 G/D; Flange PN40; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0…40bar; Nominal diameter 50mm; Length 82mm; Actuator PAS1155

BA480-10-B-01

High pressure ball valve; Female thread; Body, Ball 1.4571/1.4404; Seals POM/FKM (AED); Medium temperature -40...+100°C; G 1"; Nominal diameter 25mm; Pressure range 0...420bar; Length 113mm; Flange ISO5211 F05; Square 14mm; Free of oil and grease

BA480-10-L-01

High pressure ball valve With hand lever; Female thread; Body, Ball 1.4571/1.4404; Seals POM/FKM (AED); Medium temperature -40...+100°C; G 1"; Nominal diameter 25mm; Pressure range 0...500bar; Length 113mm; Free of oil and grease

BA028-10-0E-C

Ball valve with electrical actuator; Female thread; Body Steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; RP 1"; DN 25mm; Pressure range 0-40bar; Length 92mm; Operating time 15s; Voltage 24VAC/DC; Actuator: Protection class IP67; CSA-Certified

BA162-20-S0-AH

Ball valve with pneumatic actuator; ATEX II 2G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R101; Flange PN100; Full bore; Body Stainless steel AISI 316, Ball 1.4404; Seals PTFE/FKM/Graphite; Pressure range 0...100bar; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 20mm; Pressure range 0...100bar; Length 60mm; Actuator PAS0755; Free of oil and grease for hydrogen

BA162-20-S0-AH3C

BA051-20-PH

Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body, Ball 1.4408; Stem seal 2-fold PTFE/FKM-Packing; Medium temperature -20...+160°C; DN 20mm; Pressure range 0-40bar; Flange PN40; Length 120mm; Operating time 8s; Voltage 100-240VAC; Accumulator for safety position NC
