Ball valves - automatically operated

Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 11/2"; DN 40mm; Pressure range 0-10bar; Length 138,5mm; Operating time 9s; Voltage 24VAC/DC; Ball T; Flow path 02

BA162-25-D0-A-01

Flanged ball valve with pneumatic actuator; ATEX II 2 G/D; Fire-safe; TA-Luft; Flange PN100; Body, Ball 1.4401; Seals PTFE-metal reinforced/Graphoil/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...100bar; Nominal diameter 25mm; Length 65mm; Actuator PAD063

BA080-112-0F-C

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 11/2"; DN 40mm; Pressure range 0-40bar; Length 114mm; Operating time 7s; Voltage 100-240VAC; Electrical actuator CSA-Certified

BA179-25-0H

Flanged ball valve with electrical actuator; Fire safe/anitstatic according to ATEX/TA-Luft certification; Flange PN100, Full bore; Body steel A350-LF2, Ball 1.4301; Seals PTFE/FKM/Graphite; Pressure range 0...100bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Length 65mm Operating time 8s; Voltage 100-240VAC

BA146-50-D0-01

STASTO Combination#br#Ball valve with pneumatic actuator; Butt weld ends Long; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Pressure range 0-25bar; Length 336mm; Actuator PAD075; Limit switch box EB0X03; 5/2-way solenoid valve - NAMUR type ABS54; 24VDC-LED

BA080-212-0Q

Ball valve with electrical actuator; Female thread; Body, Ball Brass; Seals PTFE/FKM/EPDM; Medium temperature 0...+100°C; RP 21/2"; DN 65mm; Pressure range 0-25bar; Length 165mm; Operating time 79s; Voltage 100-240V/50-60Hz; 100-350VDC; Actuator ER60-0Q79-Q22

BADA-050-SSTV-S2

Flanged ball valve series 721000 flange PN16, DN50, full bore body and ball 1.4401, seals PTFE/FKM with single-acting pneumatic rotary actuator control pressure 4-8bar

BA137-50-S0-A

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Antistatic design; ATEX; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator PAS1005

BA033-20-PL

Ball valve with electrical actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; RP 2"; DN 50mm; Pressure range 0-25bar; Length 136mm; Operating time 9s; Voltage 24VAC/DC; NC-Accumulator for safety position

BA481-40-S0

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE-Carbographite/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -30...+160°C; Pressure range 0...16bar; Nominal diameter 40mm; Length 63,5mm; Actuator PAS1005

BA081-112-0F-C

Ball valve with electrical actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; RP 11/2"; DN 40mm; Pressure range 0-64bar; Length 112mm; Operating time 7s; Voltage 100-240VAC; Electrical actuator CSA-Certified

BA262-25-S0-A

Flanged ball valve with pneumatic actuator API608; ATEX II 2 G/D c T3; Fire-Safe/Antistatik According to ATEX/TA-Luft; Length According to ASME B16.10; Full bore; Flange ANSI 150; Body, Ball 1.4408; Seals Reinforced PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+180°C; Pressure range 0...20bar; Nominal diameter 25mm; Length 127mm; Actuator PAS0855

BA341-40-S0-A-01

Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Body Ball 1.4401; Seals Fibre-glass-reinforced PTFE Thickness Reduced/FFKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 40mm; Pressure range 0-40bar; Flange PN40; Length 63,5mm; Actuator PAS1005

VB060M-PF9-Q14

Electrical actuator; Metal; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 60Nm; Operating time 9s; Flange ISO5211 F05/F07-star 14mm; Voltage 100-240VAC; Protection class IP68; Including Accumulator for safety position NC

BARA-080-CITV-D0

Ball valve with pneumatic rotary actuator 85 double-acting, body 1.0432, ball 1.4308, flange PN 16 connection DN80

BAH1-005-SSKV-T0

Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4571; Seals PEEK/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; For hydraulic liquids; G 3/4"; Nominal diameter 20mm; Pressure range 0-400bar; Length 96mm; Actuator PAS1005; Safety position NO

BA137-25-D0-A-01

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Antistatic design; ATEX; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 25mm; Length 46mm; Actuator PAD052; Mounted limit switch box EB0X05; Mounted pilot valve ABS51-230V/50-60Hz-ATEX

BA185-40-0L-01

Flanged ball valve with electrical actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; DN 40mm; Pressure range 0-16bar; Length 63,5mm; Operating time 9s; Voltage 24VAC/DC; Free of oil and grease for oxygen

0DVK21

Pneumatic actuator; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 100mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 68Nm;

VRX25-0M10-Q17

Electrical actuator; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Protection class IP68; ATEX II 2 G D Ex db IIB T6 Gb Ex tb IIIC T80°C Db; c; Torque 25Nm; Operating time 10s; Flange ISO5211 F05/F07-star 17mm; Voltage 400V/50-60Hz;
