Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA261-50-S0-AH3C-EB0X14
BA261-50-S0-AH3C
Flanged ball valve with pneumatic actuator Series BA261-S0-AH3C; Fire-Safe/Antistatik According to ATEX/TA−Luft; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Pressure range 0-40bar; Flange PN40; Length 84mm; Actuator PAS1155; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
EB0X14
Mounted limit switch box; IP65; Inductive dual proximity switch, Suitable for Actuators PAD/PAS052-270; Switching capacity 8VDC/3mA; Switch type P&F NCN3-F25F-N4; Function NC contact-Namur - ATEX; Material of case Plastic
BA846-80-S0-01
Flanged ball valve with pneumatic actuator Series BA846; Flange ANSI150; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+170°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 118mm; Actuator PAS1255
BA846-100-S0-01
Flanged ball valve with pneumatic actuator Series BA846; Flange ANSI150; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+170°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 140mm; Actuator PAS1605
BA028-114-0L-01
Ball valve with electrical actuator; Female thread; Body Steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; RP 11/4"; DN 32mm; Pressure range 0-25bar; Length 106mm; Control ball V 30...60°; Operating time 119s; Voltage 15-30V/50-60Hz, 12-48VDC
RI4271
Mounting bracket; F05/F03-F04; Bolt 11-8; Screws Stainless steel
RIXX01
Mounting bracket; F05/F03-F04; Bolt 11-7; Screws Stainless steel
RI5639
Mounting bracket; F05/F03-F04; Bolt 11-7; Mounting bracket And Screws Stainless steel
RI4756
Mounting bracket; F07/F07; Bolt 17-14; Screws Stainless steel
RI4436
Mounting bracket; F07/F07; Bolt 17-14; Screws Stainless steel
BA848-10-PV-AH
Ball valve with electrical actuator; Female thread; Body 1.4404 Polished, Ball 1.4404; Seals MPTFE/FKM; Full bore; Medium temperature -20...+170°C; Welding ends According to ASTM A-270 12.7 x 1.65; DN 10mm; Pressure range 0…100bar; Length 88mm; Operating time 7s; Voltage 24-30V/50-60Hz; 24-48VDC; Ball L; Incl. Accumulator for safety position NC; ATEX II 2 G D Ex db IIB T6 Gb Ex tb IIIC T80°C Db; c; Free of oil and grease for hydrogen
BA848-10-S0-AH
Ball valve with pneumatic actuator; ATEX II 2 G/D T4; Female thread; Body 1.4404 Polished; Ball 1.4404; Seals MPTFE/FKM; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+170°C; Welding ends According to ASTM A-270 12.7 x 1.65; Nominal diameter 10mm; Pressure range 0...100bar; Length 88mm; Actuator PAS0525; Free of oil and grease for hydrogen
VB110M-0E27-Q17-01
Electrical actuator Series VBM-UL; Metal; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 110Nm; Operating time 27s; Flange ISO5211 F07/F10-star 17mm; Voltage 24VAC/DC; Protection class IP68; With UL-Approval; Thread UNC
BA531-112N-B-AH
Ball valve made of stainless steel; ATEX II 2 G/D T4 ; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE/FKM; Medium temperature -20...+160°C; Female thread 11/2"NPT; Nominal diameter 40mm; Length 134mm; Pressure range 0-64bar; Ball T; For mounting an actuator F07/17mm; Free of oil and grease for hydrogen
BA531-112N-S0-AH
Ball valve with pneumatic actuator; ATEX II 2 G/D T4; 3-way-type; Ball is sealed on all sides; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Female thread 11/2NPT"; Nominal diameter 40mm; Pressure range 0...64bar; Length 134mm; Actuator PAS1155; Ball T; Free of oil and grease for hydrogen
EB0X90X
Limit switch box; IP67/68; 4 Micro switches; Switching capacity 4A/230V AC/DC; Switch type Crouzet 83.161.301 (DPDT); Contact material Silver-nickel; Material of case Aluminum; 2x Cable inlet 1/2"NPT; Temperature range -40...+85°C; Including visual indication Yellow/Red; ATEX II2G Ex db IIC T6...T4 Gb; II2D Ex tb IIIC T80°C...T105°C Db; Incl. Marking IECEx
EB0X90​-WSTHVB
Mounted limit switch box; IP67/68; 4 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/230V AC/DC; Switch type Crouzet 83.161.301 (DPDT); Contact material Silver-nickel; Material of case Aluminum; 2x Cable inlet 1/2"NPT; Temperature range -40...+85°C; Including visual indication Yellow/Red; ATEX II2G Ex db IIC T6...T4 Gb; II2D Ex tb IIIC T80°C...T105°C Db; Incl. Marking IECEx
BAEB-050-SSTV-S0A-ABS53-EPC02400-1-EB0X05
BAEB-050-SSTV-S0A
Kugelhahn mit Druckluftdrehantrieb,100
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
EPC02400-1
Mounted coil Type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; Cable length 3m; Voltage 24VDC
EB0X05
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831391 - ATEX; Contact material Silber-Nickel; Material of case Plastic
BA140-20-D0-ABS51-C001-22-C002-31-6
BA140-20-D0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Without dead space; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0-25bar; Length 136mm; Actuator PAD075
ABS51
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); Actuator PAD052-270
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC
ABS100
Mounted pilot valve; Pilot-operated; Actuation Electric/Internal control air; Body Aluminium; Temperature range -10...+50°C; Standard coil MA22; Connector size 22mm; Connection 1/4"NPT; Function NC; Pressure range 2-10bar; Flow rate 1250Nl/min; 3/2-way solenoid valve - NAMUR type (MNH 310 701 NPT); Actuator PAS052-270
BA086-125-D2-A-02
Flanged ball valve with pneumatic actuator ATEX II 2G Ex h IIC T6...T1 Gb / II 2D Ex h IIIC T85°C...T450°C Db; Fire-safe; TA-Luft; Flange PN16; Body And Ball 1.4401; Seals PTFE-Graphite/FKM; Double acting actuator; ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T85°C Db; Control pressure 4...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 125mm; Length 196mm; Actuator PAD125; Flat sealing face; Without grooves; With mounted fittings 8mm
