| Female thread | DN | Length | Connector | Voltage | Pressure | Seal | Medium temperature | Voltage type | Design | Approval | Type | Sequence |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| G 1/4" | 4 mm | 37 mm | - | 110VDC | 0...3 bar | - | - | - | - | - | SL001-14-4-A07 | 20620009 |
| G 1/4" | 4 mm | 37 mm | - | 110V/50-60Hz | 0…6 bar | - | - | - | - | - | SL001-14-4-A13 | 20620010 |
| G 1/4" | 4 mm | 37 mm | - | 220-230V/50-60Hz | 0…6 bar | - | - | - | - | - | SL001-14-4-A01 | 20620011 |
2/2-way solenoid valve Series SL035
Combined operated; NO; Body Stainless steel AISI 316; Tube Stainless steel One-piece
Grundversion
| Female thread | DN | Length | Function | Connector | Voltage | Pressure AC/DC | Seal | Medium temperature | Type | Sequence |
|---|---|---|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - | - | SL035-12-AS03 | 20630000 |
| G 3/8" | 15 mm | 68 mm | - | - | 24V/50-60Hz | - | - | -10...+120 °C | SL035-38-AS04 | 20630001 |
2/2-way solenoid valve Series 21L1K1T, 21L2K1T
Directly operated; NC; Body Stainless steel 1.4401; Tube Stainless steel One-piece; Seal PTFE; Medium temperature -40...+120°C; Standard coil BDA; Connector size 32mm
Grundversion
| Female thread | DN | Length | Pressure AC | Pressure DC | Voltage | Voltage type | Design | Approval | Type | Sequence |
|---|---|---|---|---|---|---|---|---|---|---|
| G 1/4" | 2,5 mm | 39 mm | 0...14 bar | 0...9 bar | - | - | - | - | 21L2K1T25 | 20630001 |
Varianten
| Female thread | DN | Length | Pressure AC | Pressure DC | Voltage | Voltage type | Design | Approval | Type | Sequence |
|---|---|---|---|---|---|---|---|---|---|---|
| G 1/4" | 2,5 mm | 39 mm | 0...14 bar | 0...9 bar | 24VDC | DC | Standard | CE | 21L2K1T25-BDA08024CS-C003-32-6 | 20630002 |
2/2-way solenoid valve Series SL035
Combined operated; NO; Body Stainless steel AISI 316; Tube Stainless steel One-piece
Grundversion
| Female thread | DN | Length | Function | Connector | Voltage | Pressure AC/DC | Seal | Medium temperature | Type | Sequence |
|---|---|---|---|---|---|---|---|---|---|---|
| G 3/8" | 15 mm | 68 mm | - | - | 24VDC | - | - | -10...+120 °C | SL035-38-AS03 | 20630002 |
| G 3/8" | 15 mm | 68 mm | - | - | 220-230V/50-60Hz | - | - | -10...+120 °C | SL035-38-AS01 | 20630003 |
2/2-way solenoid valve Series 21L1K1T, 21L2K1T
Directly operated; NC; Body Stainless steel 1.4401; Tube Stainless steel One-piece; Seal PTFE; Medium temperature -40...+120°C; Standard coil BDA; Connector size 32mm
Grundversion
| Voltage | Type | Sequence |
|---|---|---|
| 0-230VAC | C003-32-V-3-R | 20640000 |
| 230VAC | C003-32-LV-3-R | 20640001 |
| 24VAC | C003-32-LV-5-R | 20640002 |
Grundversion
| Voltage | Voltage type | Approval | Type | Sequence |
|---|---|---|---|---|
| 12VDC | DC | CE | UDA12012CS | 20650000 |
| 24V/50-60Hz | AC | CE | UDA12024AS | 20650001 |
| 24VDC | DC | CE | UDA12024CS | 20650002 |
| 230V/50Hz | AC | CE | UDA12230AS | 20650003 |
| 230V/50Hz | AC | CE | UDV12230DW | 20650004 |
| Female thread | DN | Length | Connector | LED | Voltage | Pressure AC | Pressure DC | Pressure | Type |
|---|---|---|---|---|---|---|---|---|---|
| G 3/8" | 12 mm | 50 mm | Standard | - | 24VDC | - | 0,1...10 bar | 0,1...10 bar | SL008-38-AS03 |
